Tractor · 2016Unverified

Kioti RX8030

Name: Kioti RX8030
Brand: Kioti

Kioti RX8030 — Utility tractor · 76 hp. Reference specifications; pending source verification.

The Kioti RX8030 is a 76 hp tractor, situated in the middle of its class in terms of power output. It was manufactured in 2016. The RX8030 is equipped with a 4-cylinder turbocharged diesel liquid-cooled engine, which drives four-wheel drive via a 24-speed gearbox. Its weight ranges from 5600 to 6162 pounds, suitable for tasks covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

76 hp

Weight

5600 to 6162 pounds

Catalogue coverage

Variants represented

Richest spec table

53 rows

Recorded power

76 hp

Recorded weight

2540 kg

Transmissions

24-speed power shuttle

Production years

2016-2016

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerKioti (a part of Daedong)Reference

Utility tractorReference

Built in South KoreaReference

Four-wheel driveReference

Differential lockmechanical rearReference

Power steeringReference

Wet disc brakesReference

Two-post ROPS. Cab available with air-conditioning.Reference

Engine

Daedong 2.4L 4-cyl dieselReference

ROPS Fuel tank85.2 LReference

Cab Fuel tank95.0 LReference

Engine (gross)56.7 kWReference

Daedong 4FT-TP2-AReference

turbocharged dieselReference

4-cylinderReference

liquid-cooledReference

Displacement2.4 LReference

Bore/Stroke87 x 102 mmReference

Power (gross)56.7 kWReference

Rated RPM2500Reference

StarterelectricReference

Starter volts12Reference

Transmission

24-speed power shuttleReference

Typepower shuttleReference

Gears24 forward and reverseReference

Clutchhydraulic wet discReference

PTO & Hydraulics

Typeopen centerReference

Pump flow41.6 lpmReference

Total flow72.7 lpmReference

Steering flow31.0 lpmReference

Rear TypeIIReference

Controlposition and draft controlReference

Rear lift (at 24"/610mm)2256 kgReference

Rear PTOindependentReference

Rear PTO Type540/540EReference

Dimensions

Wheelbase213 cmReference

Weight5600 to 6162 poundsReference

Front tire280/85R24Reference

Rear tire420/85R30Reference

Standard tires (ag)Front: 280/85R24. Rear: 420/85R30Reference

Length370 cmReference

Width196 cmReference

Height (ROPS)273 cmReference

Height (cab)265 cmReference

ROPS Weight2540 kgReference

Cab Weight2795 kgReference

Ground clearance43 cmReference

Kioti RX8030 attachments

front-end loaderReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Battery volts12Reference

Attachment overview

Kioti KL601 loaderReference

Kioti KL701 loaderReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
