Kioti RX8030
Kioti RX8030 — Utility tractor · 76 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
76 hp
Weight
5600 to 6162 pounds
Hover a source tag to verify
Overview
ManufacturerKioti (a part of Daedong)Reference
Utility tractorReference
Built in South KoreaReference
Four-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Wet disc brakesReference
Two-post ROPS. Cab available with air-conditioning.Reference
Engine
Daedong 2.4L 4-cyl dieselReference
ROPS Fuel tank85.2 LReference
Cab Fuel tank95.0 LReference
Engine (gross)56.7 kWReference
Daedong 4FT-TP2-AReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.4 LReference
Bore/Stroke87 x 102 mmReference
Power (gross)56.7 kWReference
Rated RPM2500Reference
StarterelectricReference
Starter volts12Reference
Transmission
24-speed power shuttleReference
Typepower shuttleReference
Gears24 forward and reverseReference
Clutchhydraulic wet discReference
PTO & Hydraulics
Typeopen centerReference
Pump flow41.6 lpmReference
Total flow72.7 lpmReference
Steering flow31.0 lpmReference
Rear TypeIIReference
Controlposition and draft controlReference
Rear lift (at 24"/610mm)2256 kgReference
Rear PTOindependentReference
Rear PTO Type540/540EReference
Dimensions
Wheelbase213 cmReference
Weight5600 to 6162 poundsReference
Front tire280/85R24Reference
Rear tire420/85R30Reference
Standard tires (ag)Front: 280/85R24. Rear: 420/85R30Reference
Length370 cmReference
Width196 cmReference
Height (ROPS)273 cmReference
Height (cab)265 cmReference
ROPS Weight2540 kgReference
Cab Weight2795 kgReference
Ground clearance43 cmReference
Kioti RX8030 attachments
front-end loaderReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Attachment overview
Kioti KL601 loaderReference
Kioti KL701 loaderReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
