Tractor · 1975Unverified
Kirovets K-701
Kirovets K-701 — Four-wheel Drive (4WD) tractor · 260 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
260 hp
Weight
27560 to 29760 pounds
Hover a source tag to verify
Overview
ManufacturerKirovetsReference
Four-wheel Drive (4WD) tractorReference
Built in Saint Petersburg, RussiaReference
Four-wheel driveReference
Articulated power steeringReference
Pneumatic drum brakesReference
Cab standard.Reference
Variants
7100similar Belarus modelReference
Engine
YaMZ 22.3L 12-cyl dieselReference
Engine223.7 kWReference
YaMZ 240Reference
dieselReference
12-cylinderReference
liquid-cooled V-12Reference
Displacement22.3 LReference
Bore/Stroke130 x 140 mmReference
Power223.7 kWReference
Fuel systemdirect injectionReference
Air cleanerdryReference
Compression16.5:1Reference
Rated RPM1900Reference
Firing order1-12-5-8-3-10-6-7-2-11-4-9Reference
Starter typeelectricReference
Oil capacity45.0 LReference
Transmission
16-speed four-speed power shiftReference
Typefour-speed power shiftReference
Gears16 forward and 8 reverseReference
Oil capacity23.0 LReference
Four power shift gears in four ranges.Reference
PTO & Hydraulics
PTO (claimed)193.9 kWReference
Hydraulic system126.0 LReference
Typeopen centerReference
Capacity126.0 LReference
Valves2Reference
Pump flow90.1 lpmReference
Rear TypeIVReference
Rear PTOindependentReference
Rear PTO Type1000Reference
Capacities
Fuel640.0 LReference
Dimensions
Wheelbase320 cmReference
Weight27560 to 29760 poundsReference
Front tire28.1x26Reference
Rear tire28.1x26Reference
Ag front28.1x26Reference
Ag rear28.1x26Reference
Length739 cmReference
Width288 cmReference
Height355 cmReference
Shipping weight12501 kgReference
Operating weight13499 kgReference
Front tread211 cmReference
Rear tread211 cmReference
Electrical
Charging systemalternatorReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
