Tractor · 1988Unverified
Kirovets K-701M
Kirovets K-701M — Four-wheel Drive (4WD) tractor · 335 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
335 hp
Weight
14605 kg
Hover a source tag to verify
Overview
ManufacturerKirovetsReference
Four-wheel Drive (4WD) tractorReference
Built in Saint Petersburg, RussiaReference
Four-wheel driveReference
Articulated power steeringReference
Pneumatic drum brakesReference
Cab standard with air-conditioning.Reference
Engine
YaMZ 17.2L 8-cyl dieselReference
Engine249.8 kWReference
YaMZ 8423Reference
turbocharged dieselReference
8-cylinderReference
liquid-cooled V-8Reference
Displacement17.2 LReference
Bore/Stroke140 x 140 mmReference
Power249.8 kWReference
Rated RPM1900Reference
Starter typeelectricReference
Transmission
16-speed four-speed power shiftReference
Typefour-speed power shiftReference
Gears16 forward and 8 reverseReference
Clutchwet discReference
Four power shift gears in four ranges.Reference
Capacities
Fuel599.9 LReference
PTO & Hydraulics
Hydraulic system180.2 LReference
Capacity180.2 LReference
Pump flow71.2 lpmReference
Rear TypeIVReference
Rear PTOindependentReference
Rear PTO Type1000Reference
Dimensions
Wheelbase389 cmReference
Weight14605 kgReference
Front tire30.5R32Reference
Rear tire30.5R32Reference
Ag front30.5R32Reference
Ag rear30.5R32Reference
Length750 cmReference
Width284 cmReference
Height (cab)379 cmReference
Height (exhaust)404 cmReference
Electrical
Charging systemalternatorReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
