Tractor · 1981Unverified

Knudson 4360

Knudson 4360 — Four-wheel Drive (4WD) tractor · 360 hp. Reference specifications; pending source verification.

The Knudson 4360 is a tractor with a rated power of 360 hp, placing it at the higher end of its class. Built from 1981 to 1983, this model is equipped with a 6-cylinder diesel liquid-cooled engine, paired with a four-wheel drive and powershift transmission. It has an operating weight of 17,917 kg and is suitable for operations covering 1,500+ acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power
360 hp
Weight
17917 kg

Catalogue coverage

Variants represented
2
Richest spec table
42 rows
Recorded power
360 hp
Recorded weight
17917 kg
Transmissions
12-speed power shift
Production years
1981-1983
Verified variants
0

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerKnudsonReference
Four-wheel Drive (4WD) tractorReference
Built in Holdrege, Nebraska, USAReference
Original price was $155,000 in 1981Reference
Drive4x4 4WDReference
Power four-wheel steeringReference
Hydraulic wet disc brakesReference
Cab standard.Reference

Engine

Cummins 14.0L 6-cyl dieselReference
Fuel tank1324.8 LReference
Engine (gross)268.5 kWReference
Cummins NTA-855-CReference
dieselReference
6-cylinderReference
liquid-cooledReference
Displacement14.0 LReference
Bore/Stroke140 x 152 mmReference
Power (gross)268.5 kWReference
Rated RPM2100Reference
Torque1457.7 NmReference
Torque RPM1450Reference
Starter volts24Reference

Transmission

12-speed power shiftReference
ManufacturerTwin DiscReference
Typepower shiftReference
Gears12 forward and 2 reverseReference

PTO & Hydraulics

Pressure137.9 barReference
Valves4Reference
Pump flow98.4 lpmReference
Pump flow45.4 lpmReference
Total flow143.8 lpmReference

Dimensions

Weight17917 kgReference
Front tire30.5L-32Reference
Rear tire30.5L-32Reference
Ag front30.5L-32Reference
Ag rear30.5L-32Reference
Ag front20.8-38Reference
Ag rear20.8-38Reference

Electrical

GroundnegativeReference
Charging systemalternatorReference
Charging amps90Reference
Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
