Tractor · 1992Unverified
Kubota A-155
Kubota A-155 — Aste Series · 16 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
16 hp
Weight
664 kg
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Sub-Compact Utility tractorReference
Four-wheel driveReference
Two-post ROPS.Reference
Engine
Kubota 0.9L 3-cyl dieselReference
Fuel tank17.0 LReference
Engine11.8 kWReference
Kubota D905Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement0.9 LReference
Bore/Stroke72 x 74 mmReference
Power11.8 kWReference
Rated RPM2650Reference
StarterelectricReference
Starter volts12Reference
Transmission
6-speedReference
Gears6 forward and 2 reverseReference
PTO & Hydraulics
Rear Type0Reference
Rear PTO Type540 (1.375)Reference
Engine RPM450@2650Reference
Engine RPM795@2650Reference
Engine RPM1187@2650Reference
Engine RPM-612@2650Reference
Dimensions
Wheelbase135 cmReference
Weight664 kgReference
Front tire5.00-12Reference
Rear tire8-16Reference
Standard tires (ag)Front: 5.00-12. Rear: 8-16Reference
Length253 cmReference
Width104 cmReference
Height180 cmReference
Ground clearance29 cmReference
Front tread82 cmReference
Rear tread81/89 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
