Tractor · 1985Unverified
Kubota B1-16
Kubota B1-16 — Bulltra Series · 17 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
17 hp
Weight
1422 to 1521 pounds
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Sub-Compact Utility tractorReference
Built in JapanReference
Two- or four-wheel driveReference
SteeringmanualReference
Open operator station.Reference
Variants
B1-16D4WDReference
Engine
Kubota 0.9L 3-cyl dieselReference
Fuel tank17.0 LReference
Engine12.3 kWReference
Kubota D950Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement0.9 LReference
Bore/Stroke75 x 70 mmReference
Power12.3 kWReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed unsynchronized gearReference
Typeunsynchronized gearReference
Gears12 forward and 4 reverseReference
Three gears (1-3), plus reverse, in two ranges with additional creeper range.Reference
PTO & Hydraulics
Rear Type0Reference
Rear PTO Type540/860/1000 (1.375)Reference
Dimensions
Wheelbase135 cmReference
Weight1422 to 1521 poundsReference
Front tire4.00-12Reference
2WD Rear tire8.3-20Reference
2WD Standard tires (ag)Front: 4.00-12. Rear: 8.3-20Reference
4WD Standard tires (ag)Front: 5.00-12. Rear: 8.3-20Reference
Length231 cmReference
Width115 cmReference
2WD Height123 cmReference
4WD Height123 cmReference
2WD Weight645 kgReference
4WD Weight689 kgReference
2WD Front tread73 cmReference
4WD Front tread76 cmReference
Rear tread90/103 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
