Tractor · 1985Unverified

Kubota B1-17

Name: Kubota B1-17
Brand: Kubota

Kubota B1-17 — Bulltra Series · 17 hp. Reference specifications; pending source verification.

The Kubota B1-17 is a compact tractor with a 17 hp engine rating, making it one of the smaller models in its class. It was produced between 1985 and 1988. The tractor features a 3-cylinder diesel liquid-cooled engine, with a four-wheel drive system and a 12-speed gearbox. Its listed weight is 1433 to 1532 pounds, and it is designed for use on areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

17 hp

Weight

1433 to 1532 pounds

Catalogue coverage

Variants represented

Richest spec table

43 rows

Recorded power

17 hp

Recorded weight

650 kg

Transmissions

12-speed unsynchronized gear

Production years

1985-1988

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Sub-Compact Utility tractorReference

Built in JapanReference

Two- or four-wheel driveReference

SteeringmanualReference

Open operator station.Reference

Variants

B1-17D4WDReference

Engine

Kubota 0.9L 3-cyl dieselReference

Fuel tank17.0 LReference

Engine12.7 kWReference

Kubota D950Reference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement0.9 LReference

Bore/Stroke75 x 70 mmReference

Power12.7 kWReference

Rated RPM2600Reference

StarterelectricReference

Starter volts12Reference

Transmission

12-speed unsynchronized gearReference

Typeunsynchronized gearReference

Gears12 forward and 4 reverseReference

Three gears (1-3), plus reverse, in two ranges with additional creeper range.Reference

PTO & Hydraulics

Rear Type0Reference

Rear PTO Type540/860/1000 (1.375)Reference

Dimensions

Wheelbase135 cmReference

Weight1433 to 1532 poundsReference

Front tire4.00-12Reference

2WD Rear tire8.3-22Reference

2WD Standard tires (ag)Front: 4.00-12. Rear: 8.3-22Reference

4WD Standard tires (ag)Front: 5.00-12. Rear: 8.3-22Reference

Length233 cmReference

Width115 cmReference

Height124 cmReference

2WD Weight650 kgReference

4WD Weight694 kgReference

Ground clearance23 cmReference

2WD Front tread73 cmReference

4WD Front tread76 cmReference

Rear tread90 to 103 cmReference

Electrical

GroundnegativeReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
