The Kubota B1181 is a compact tractor model with a rated output of 17 hp, featuring a 3-cylinder diesel liquid-cooled engine. This model was manufactured in 2018 and is equipped with four-wheel drive and a 6-speed gearbox. The listed weight of the B1181 is 640 kg, making it suitable for use in areas of approximately 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
17 hp
Weight
640 kg
Catalogue coverage
Variants represented
2
Richest spec table
45 rows
Recorded power
17 hp
Recorded weight
640 kg
Transmissions
6-speed gear
Production years
2018-2018
Verified variants
0
1 linked source document displayed
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Sub-Compact Utility tractorReference
Four-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS.Reference
Engine
Kubota 0.8L 3-cyl dieselReference
Fuel tank14.0 LReference
Engine (net)13.0 kWReference
Kubota D782Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement0.8 LReference
Bore/Stroke67 x 74 mmReference
Rated Power (net)13.0 kWReference
Air cleanerdry elementReference
Rated RPM3000Reference
StarterelectricReference
Starter volts12Reference
Transmission
6-speed gearReference
TypegearReference
Gears6 forward and 2 reverseReference
PTO & Hydraulics
Pump flow14.4 lpmReference
Rear TypeIReference
Rear lift (at ends)540 kgReference
Rear PTO Type540/1000 (1.375)Reference
Mid PTOoptionalReference
Mid PTO Type2500 (Kubota 10-tooth #5)Reference
Dimensions
Wheelbase127 cmReference
Weight640 kgReference
Front tire5-12Reference
Rear tire8-16Reference
Standard tires (ag)Front: 5-12. Rear: 8-16Reference
Length235 cmReference
Width93 cmReference
Height (ROPS)221 cmReference
Ground clearance24 cmReference
Front tread76 to 86 cmReference
Rear tread75 to 100 cmReference
Kubota B1181 attachments
front-end loaderReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
