Tractor · 1979Unverified
Kubota B1400
Kubota B1400 — B00 Series · 14 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
14 hp
Weight
498 kg
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Sub-Compact Utility tractorReference
Built in JapanReference
Two- or four-wheel driveReference
SteeringmanualReference
Open operator station.Reference
Engine
Kubota 0.9L 3-cyl dieselReference
Engine14.2 kWReference
Kubota D850LReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement0.9 LReference
Power14.2 kWReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
6-speed unsynchronized gearReference
Typeunsynchronized gearReference
Gears6 forward and 2 reverseReference
PTO & Hydraulics
PTO (claimed)10.4 kWReference
Rear TypeIReference
Rear PTO Type540/860/1000 (1.375)Reference
Dimensions
Wheelbase124 cmReference
Weight498 kgReference
Front tire5.00-12Reference
Rear tire8-16Reference
Ag front5.00-12Reference
Ag rear8-16Reference
Length217 cmReference
Width104 cmReference
Height123 cmReference
Ground clearance23 cmReference
Front tread76 cmReference
Rear tread75 to 86 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
