The Kubota B1402 is a tractor model rated at approximately 14 hp, categorising it as a lighter model within its class. Produced from 1981 to 1985, the B1402 is equipped with a 3-cylinder diesel liquid-cooled engine, paired with four-wheel drive and a 6-speed gearbox. Its operating weight is listed at 498 kg, and it is suitable for use on areas of up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
14 hp
Weight
498 kg
Catalogue coverage
Variants represented
2
Richest spec table
38 rows
Recorded power
14 hp
Recorded weight
498 kg
Transmissions
6-speed unsynchronized gear
Production years
1981-1985
Verified variants
0
1 linked source document displayed
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Sub-Compact Utility tractorReference
Built in JapanReference
Two- or four-wheel driveReference
Manual steeringReference
Open operator station.Reference
Variants
B1402E2WDReference
B1402DT4WDReference
Engine
Kubota 0.9L 3-cyl dieselReference
Engine10.3 kWReference
Kubota D850LReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement0.9 LReference
Power10.3 kWReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
6-speed unsynchronized gearReference
Typeunsynchronized gearReference
Gears6 forward and 2 reverseReference
PTO & Hydraulics
Rear TypeIReference
Rear PTO Type540/860/1000 (1.375)Reference
Dimensions
Wheelbase124 cmReference
Weight498 kgReference
Front tire5.00-12Reference
Rear tire8-16Reference
Ag front5.00-12Reference
Ag rear8-16Reference
Length217 cmReference
Width104 cmReference
Height123 cmReference
Ground clearance23 cmReference
Front tread76 cmReference
Rear tread75 to 86 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
