Tractor · 1995Unverified

Kubota B1700

Name: Kubota B1700
Brand: Kubota

Kubota B1700 — Compact Utility tractor · 17 hp. Reference specifications; pending source verification.

The Kubota B1700 is a compact tractor with a rated power output of 17 hp, positioning it within the lower power range of its class. This model was manufactured from 1995 to 1999. It features a 3-cylinder diesel liquid-cooled engine, paired with four-wheel drive and a hydrostatic transmission. The tractor has a listed operating weight of 680 kg and is suitable for working on areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

17 hp

Weight

680 kg

Catalogue coverage

Variants represented

Richest spec table

98 rows

Recorded power

17 hp

Recorded weight

680 kg

Transmissions

6-speed gear

Production years

1995-1999

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Compact Utility tractorReference

Two- or four-wheel driveReference

SteeringpowerReference

Wet disc brakesReference

Two-post ROPS.Reference

Engine

Kubota 0.9L 3-cyl dieselReference

Engine (gross)12.7 kWReference

Kubota D905-D10Reference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement0.9 LReference

Bore/Stroke72 x 74 mmReference

Power (gross)12.7 kWReference

Fuel systemindirect injectionReference

Rated RPM2600Reference

Torque51.5 NmReference

Starter volts12Reference

Oil capacity3.4 LReference

Coolant capacity3.4 LReference

Fuel TypeDieselReference

No of Cylinders3-cylinderReference

Rated engine speed2,600Reference

Engine torque at rated speed17.2 kgReference

Bore and stroke2.83x2.90 inchesReference

Cooling systemliquid-cooledReference

Transmission

6-speed gearReference

hydrostaticReference

TypegearReference

Gears6 forward and 2 reverseReference

TypehydrostaticReference

Gearsinfinite forward and reverse (2-range)Reference

Oil capacity6.0 LReference

PTO & Hydraulics

Gear PTO (claimed)10.4 kWReference

Hydro PTO (claimed)9.7 kWReference

Hydraulic system11.0 LReference

Typeopen centerReference

Capacity11.0 LReference

Pump flow22.0 lpmReference

Rear TypeIReference

Controlposition controlReference

Rear lift (at ends)580 kgReference

Rear lift (at 24"/610mm)460 kgReference

Rear PTOliveReference

Rear PTO Type540 (1.375)Reference

Engine RPM540@2584Reference

Mid PTO Type2537Reference

Engine RPM2537@2600Reference

Capacities

Fuel23.8 LReference

Crankcase oil volume3.6 qtsReference

Dimensions

Wheelbase149 cmReference

Weight680 kgReference

Front tire5.00-10Reference

Rear tire8.3-16Reference

Ag front5.00-10Reference

Ag front6.00-12 (4WD)Reference

Ag rear8.3-16Reference

Length228 cmReference

Width98 cmReference

Height129 cmReference

Height (ROPS)191 cmReference

Ground clearance29 cmReference

4WD Front tread83 cmReference

Rear tread77 to 94 cmReference

Kubota B1700 attachments

54" mid-mount mower deckReference

60" mid-mount mower deckReference

snowblowerReference

front-end loaderReference

backhoeReference

Electrical

GroundnegativeReference

Battery CCA390Reference

Battery volts12Reference

Total cold cranking amps390Reference

Attachment overview

54" mid-mount mower deckReference

60" mid-mount mower deckReference

SnowblowerReference

Front-end loaderReference

BackhoeReference

Kubota B4672 Backhoe

Backhoe typeKubota B4672 BackhoeReference

Speeds

With 8.3-16 rear tires.Reference

General

Make & ModelKubotaReference

Country of manufacturerCompact Utility tractorReference

PTO

Rear PTO PowerAvailableReference

Mid PTOAvailableReference

Steering & brakes

Brakeswet discReference

Steering typepowerReference

Hydraulics

Hydraulics Typeopen centerReference

Rear Hitch category (SAE designation)Category IReference

Rear Hitch maximum lift capacity580.6 kgReference

Rear Hitch Sensing Typeposition controlReference

Dimensions & weight

Overall Height129.3 cmReference

Overall Length228.1 cmReference

Overall Width98.8 cmReference

Wheels & tyres

Rear wheel tread range8.3-16 inchReference

Front Wheel tread range5.00-10, 6.00-12 (4WD)Reference

Operator station

Cab AvailabilityAvailableReference

Cab Air conditioning, temperature differentialTwo-post ROPS.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
