Tractor · 2014Unverified
Kubota B2050
Kubota B2050 — B50 Series · 20 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
20 hp
Weight
724 kg
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Compact Utility tractorReference
Four-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS.Reference
Engine
Kubota 1.1L 3-cyl dieselReference
Fuel tank26.9 LReference
Engine (gross)14.7 kWReference
Engine (net)14.0 kWReference
KubotaReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.1 LReference
Bore/Stroke78 x 78 mmReference
Rated Power (net)14.0 kWReference
Power (gross)14.7 kWReference
Air cleanerdry elementReference
Rated RPM2500Reference
StarterelectricReference
Starter volts12Reference
Transmission
9-speed mechanical shuttleReference
Typemechanical shuttleReference
Gears9 forward and reverseReference
PTO & Hydraulics
PTO (claimed)11.9 kWReference
Pressure161.8 barReference
Total flow32.9 lpmReference
Rear TypeIReference
Controlposition controlReference
Rear lift (at ends)969 kgReference
Rear PTOtransmissionReference
Rear PTO Type540 (1.375)Reference
Mid PTOoptionalReference
Mid PTO Type2500 (Kubota 10-tooth #5)Reference
Dimensions
Wheelbase150 cmReference
Weight724 kgReference
Front tire6-12Reference
Rear tire8-16Reference
Standard tires (ag)Front: 6-12. Rear: 8-16Reference
Lawn/turf front22x8.50-12Reference
Lawn/turf rear31x13.5-15Reference
Length273 cmReference
Width102 cmReference
Height (ROPS)230 cmReference
Ground clearance23 cmReference
Front tread83 cmReference
Rear tread83 cmReference
Kubota B2050 attachments
137 cm mid-mount mower deckReference
152 cm mid-mount mower deckReference
front-end loaderReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Attachment overview
137 cm mid-mount mower deckReference
152 cm mid-mount mower deckReference
Front-end loaderReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
