Search/Tractor/Kubota/B2201

Tractor · 2018Unverified

Kubota B2201

Name: Kubota B2201
Brand: Kubota

Kubota B2201 — B2 Series · 20 hp. Reference specifications; pending source verification.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

20 hp

Weight

810 kg

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Compact Utility tractorReference

Four-wheel driveReference

Differential lockmechanical rearReference

Power steeringReference

Wet disc brakesReference

Two-post folding ROPS.Reference

Engine

Kubota 1.1L 3-cyl dieselReference

Fuel tank26.9 LReference

Engine (gross)14.7 kWReference

Engine (net)14.0 kWReference

KubotaReference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.1 LReference

Bore/Stroke78 x 78 mmReference

Rated Power (net)14.0 kWReference

Power (gross)14.7 kWReference

Air cleanerdry elementReference

Rated RPM2500Reference

StarterelectricReference

Starter volts12Reference

Transmission

9-speed mechanical shuttleReference

Typemechanical shuttleReference

Gears9 forward and reverseReference

PTO & Hydraulics

PTO (claimed)11.9 kWReference

Pressure161.8 barReference

Total flow32.9 lpmReference

Rear TypeIReference

Controlposition controlReference

Rear lift (at ends)969 kgReference

Rear PTOtransmissionReference

Rear PTO Type540 (1.375)Reference

Mid PTOoptionalReference

Mid PTO Type2500 (Kubota 10-tooth #5)Reference

Dimensions

Wheelbase150 cmReference

Weight810 kgReference

Length273 cmReference

Width102 cmReference

Height (ROPS)230 cmReference

Ground clearance23 cmReference

Front tread83 to 97 cmReference

Rear tread83 to 114 cmReference

Kubota B2201 attachments

137 cm mid-mount mower deckReference

152 cm mid-mount mower deckReference

front-end loaderReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Battery volts12Reference

Attachment overview
