Tractor · 2008Unverified

Kubota B2320

Name: Kubota B2320
Brand: Kubota

Kubota B2320 — B2x20 Series · 23 hp. Reference specifications; pending source verification.

The Kubota B2320 is a compact tractor model with an engine rating of 23 hp. Manufactured between 2008 and 2015, it features a 3-cylinder diesel liquid-cooled engine, which provides power through a hydrostatic transmission and four-wheel drive system. The listed weight of the model ranges from 1433 to 1477 pounds. It is designed for tasks requiring up to 200 acres of land.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

23 hp

Weight

1433 to 1477 pounds

Catalogue coverage

Variants represented

Richest spec table

126 rows

Recorded power

23 hp

Recorded weight

650 kg

Transmissions

9-speed gear

Production years

2008-2015

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Compact Utility tractorReference

Original price$11,088 (2011)Reference

Four-wheel driveReference

Differential lockrear standardReference

Steeringhydrostatic powerReference

Wet disc brakesReference

Two-post foldable ROPS. Sunshade optional.Reference

Variants

B2320DTgearReference

B2320DSDhydroReference

B2320Nnarrow chassisReference

Engine

Kubota 1.0L 3-cyl dieselReference

Engine (gross)17.2 kWReference

Kubota D1005Reference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.0 LReference

Bore/Stroke76 x 74 mmReference

Power (gross)17.2 kWReference

Air cleanerdual paper elementsReference

Rated RPM2800Reference

Starter volts12Reference

Oil capacity3.1 LReference

Coolant capacity3.9 LReference

Fuel TypeDieselReference

No of Cylinders3 CylinderReference

Rated engine speed2,800 rpmReference

Bore and stroke3.0x2.9 inchesReference

Cooling systemliquid-cooledReference

Transmission

9-speed gearReference

hydrostaticReference

Gear Weight650 kgReference

TypegearReference

Gears9 forward and 3 reverseReference

Oil capacity14.0 LReference

TypehydrostaticReference

Gearsinfinite forward and reverse (3-range)Reference

Oil capacity15.1 LReference

Transmission TypeGearReference

PTO & Hydraulics

Gear PTO (claimed)13.4 kWReference

Hydro PTO (claimed)12.7 kWReference

Gear Hydraulic system14.0 LReference

Hydro Hydraulic system15.1 LReference

Typeopen centerReference

Gear Capacity14.0 LReference

Hydro Capacity15.1 LReference

Valves1 or 2Reference

Pump flow17.8 lpmReference

Total flow31.4 lpmReference

Steering flow13.6 lpmReference

Rear Type1Reference

Rear lift (at ends)615 kgReference

Rear lift (at 24"/610mm)479 kgReference

Rear PTOtransmissionReference

Hydro Rear PTOliveReference

Rear PTO Type540/960 (1.375)Reference

Engine RPM540@2773Reference

Engine RPM960@2722Reference

Mid PTOoptionalReference

Mid PTO Type2500Reference

Engine RPM2500@2750Reference

Capacities

Fuel26.1 LReference

Capacity61.1 ciReference

Fuel tank26.1 LReference

Crankcase oil volume3.3 qtsReference

Dimensions

Wheelbase156 cmReference

Weight1433 to 1477 poundsReference

Front tire6-12Reference

Rear tire9.5-16Reference

Standard tires (ag)Front: 6-12. Rear: 9.5-16Reference

Lawn/turf front22x8.50-12Reference

Lawn/turf front23x8.50-12Reference

Lawn/turf rear33x12.50-15Reference

Industrial front23x8.50-12Reference

Industrial rear12-16.5Reference

Length238 cmReference

Width114 cmReference

Hydro Weight669 kgReference

Ground clearance30 cmReference

Front tread80 cmReference

Rear tread90 cmReference

Kubota B2320 attachments

54" mid-mount mower deckReference

60" mid-mount mower deckReference

front-end loaderReference

backhoeReference

B2320 Serial Number Location

Serial number decal on the right side of the tractor frame, above the front axle.Reference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps14.5Reference

Charging amps40Reference

Battery volts12Reference

Attachment overview

54" mid-mount mower deckReference

60" mid-mount mower deckReference

Front-end loaderReference

BackhoeReference

Kubota BH65 Backhoe

Backhoe typeKubota BH65 BackhoeReference

Digging depth203 cmReference

2-Foot flat digging depth200 cmReference

8-Foot flat digging depth143 cmReference

Reach from pivot276 cmReference

Loading height163 cmReference

Bucket force1172 kgReference

Dipperstick force765 kgReference

General

Make & ModelKubotaReference

Rollover protective structureTwo-post foldable ROPSReference

Country of manufacturerCompact Utility tractorReference

PTO

Rear PTO PowerAvailableReference

Rear PTO RPM540 RPMReference

Mid PTO RPM2,500 RPMReference

Engine Speed on Mid PTO speed2,500@2,750 RPMReference

Engine Speed on Rear PTO speed540@2,773 RPMReference

Steering & brakes

Brakeswet discReference

Steering typehydrostatic powerReference

Hydraulics

Hydraulics Typeopen centerReference

Remote Valves1 or 2 ValvesReference

Steering & Implements flow3.6 gpm (4.7 gpm)Reference

Rear Hitch category (SAE designation)Category 1Reference

Rear Hitch maximum lift capacity615.1 kgReference

Dimensions & weight

Overall Length238.5 cmReference

Overall Width114.6 cmReference

Wheels & tyres

Rear Wheel Type9.5-16Reference

Rear wheel tread range90.2 cmReference

Front Wheel Type6-12.Reference

Front Wheel tread range80 cmReference

Operator station

Cab Air conditioning, temperature differentialTwo-post foldable ROPS. Sunshade optional.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
