Tractor · 2008Unverified
Kubota B2320N
Kubota B2320N — B2x20 Series · 23 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
23 hp
Weight
1334 to 1390 pounds
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Orchard/Vineyard tractorReference
Original price$12,202 (2011)Reference
Four-wheel driveReference
Differential lockrear standardReference
Steeringhydrostatic powerReference
Wet disc brakesReference
Two-post fixed ROPS. Sunshade optional.Reference
Variants
B2320DTNgearReference
B2320HSDNhydroReference
B2320utility chassisReference
Engine
Kubota 1.0L 3-cyl dieselReference
Engine (gross)17.2 kWReference
Kubota D1005Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.0 LReference
Bore/Stroke76 x 74 mmReference
EmissionsInterim Tier IVReference
Power (gross)17.2 kWReference
Air cleanerdual paper elementsReference
Rated RPM2800Reference
StarterelectricReference
Starter volts12Reference
Oil capacity3.1 LReference
Coolant capacity3.9 LReference
Transmission
hydrostaticReference
9-speed gearReference
Gear Width89 cmReference
Gear Weight605 kgReference
Gear Front tread70 cmReference
TypehydrostaticReference
Gearsinfinite forward and reverse (3-range)Reference
Oil capacity15.1 LReference
TypegearReference
Gears9 forward and 3 reverseReference
Oil capacity14.0 LReference
PTO & Hydraulics
Gear PTO (claimed)13.4 kWReference
Hydro PTO (claimed)12.7 kWReference
Hydro Hydraulic system15.1 LReference
Gear Hydraulic system14.0 LReference
Typeopen centerReference
Hydro Capacity15.1 LReference
Gear Capacity14.0 LReference
Valves0 to 1Reference
Pump flow17.8 lpmReference
Total flow31.4 lpmReference
Steering flow13.6 lpmReference
Rear TypeIReference
Rear lift (at ends)750 kgReference
Rear lift (at 24"/610mm)589 kgReference
Rear PTOtransmissionReference
Rear PTOlive (hydro)Reference
Rear PTO Type540/960 (1.375)Reference
Engine RPM540@2773Reference
Engine RPM960@2722Reference
Mid PTOliveReference
Mid PTO Type2500Reference
Engine RPM2500@2750Reference
Capacities
Fuel26.1 LReference
Dimensions
Wheelbase156 cmReference
Weight1334 to 1390 poundsReference
Front tire5-12Reference
Rear tire8-16Reference
Standard tires (ag)Front: 5-12. Rear: 8-16Reference
Optional tires (ag)Front: 6-12. Rear: 8.3-16Reference
Length235 cmReference
Hydro Width93 cmReference
Hydro Weight630 kgReference
Ground clearance29 cmReference
Hydro Front tread77 cmReference
Rear tread70 to 74 cmReference
Electrical
GroundnegativeReference
Charging systemdynamoReference
Charging systemalternator (optional)Reference
Charging amps14.5Reference
Charging amps40 (optional)Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
