Tractor · 2014Unverified
Kubota B2350
Kubota B2350 — B50 Series · 23 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
23 hp
Weight
1664 to 2238 pounds
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Compact Utility tractorReference
Four-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS. Cab optional with air-conditioning.Reference
Engine
Kubota 1.1L 3-cyl dieselReference
Fuel tank26.9 LReference
Engine (gross)16.9 kWReference
Engine (net)15.2 kWReference
KubotaReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.1 LReference
Bore/Stroke78 x 78 mmReference
Rated Power (net)15.2 kWReference
Power (gross)16.9 kWReference
Air cleanerdry elementReference
Rated RPM2500Reference
StarterelectricReference
Starter volts12Reference
Transmission
9-speed mechanical shuttleReference
hydrostaticReference
ROPS gear754 kgReference
Typemechanical shuttleReference
Gears9 forward and reverseReference
TypehydrostaticReference
Gearsinfinite forward and reverse (3-range)Reference
PTO & Hydraulics
Gear PTO (claimed)13.0 kWReference
Hydro PTO (claimed)12.5 kWReference
Pressure161.8 barReference
Total flow32.9 lpmReference
Rear TypeIReference
Controlposition controlReference
Rear lift (at ends)969 kgReference
Gear Rear PTOtransmissionReference
Hydro Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Mid PTOoptionalReference
Mid PTO Type2500 (Kubota 10-tooth #5)Reference
Dimensions
ROPS Wheelbase150 cmReference
Cab Wheelbase155 cmReference
Weight1664 to 2238 poundsReference
Front tire6-12Reference
Rear tire9.5-16Reference
Standard tires (ag)Front: 6-12. Rear: 9.5-16Reference
Lawn/turf front22x8.50-12Reference
Lawn/turf rear31x13.5-15Reference
ROPS Length273 cmReference
Cab Length288 cmReference
Width123 cmReference
Height (ROPS)232 cmReference
Height (cab)208 cmReference
Ground clearance26 cmReference
Front tread83 cmReference
Rear tread98 cmReference
ROPS hydro785 kgReference
Cab hydro1015 kgReference
Kubota B2350 attachments
137 cm mid-mount mower deckReference
152 cm mid-mount mower deckReference
front-end loaderReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Attachment overview
137 cm mid-mount mower deckReference
152 cm mid-mount mower deckReference
Front-end loaderReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
