Tractor · 2013Unverified
Kubota B2650
Kubota B2650 — B50 Series · 26 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
26 hp
Weight
1786 to 2293 pounds
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Compact Utility tractorReference
Original price$16,572 (2014 ROPS )Reference
Original price$24,195 ( Cab )Reference
Four-wheel driveReference
Final drivesspur gearReference
Differential lockmechanical rearReference
Power steeringReference
Wet disc brakesReference
Two-post foldable ROPS. Cab optional with air-conditioning.Reference
Variants
B2650HSDROPSReference
B2650HSDCCabReference
Engine
Kubota 1.3L 3-cyl dieselReference
Fuel tank27.6 LReference
Engine (gross)19.4 kWReference
Kubota D1305Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.3 LReference
Bore/Stroke79 x 89 mmReference
EmissionsTier IVReference
Power (gross)19.4 kWReference
Air cleanerdual paper elementsReference
Rated RPM2500Reference
StarterelectricReference
Starter volts12Reference
Oil capacity4.0 LReference
Coolant capacity4.3 LReference
Transmission
hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverse (3-range)Reference
Oil capacity15.1 LReference
PTO & Hydraulics
PTO (claimed)14.5 kWReference
Typeopen centerReference
Valves1Reference
Pump flow18.9 lpmReference
Total flow32.9 lpmReference
Steering flow14.0 lpmReference
Rear TypeIReference
Controlposition controlReference
Rear lift (at ends)970 kgReference
Rear lift (at 24"/610mm)760 kgReference
Rear PTOindependentReference
ClutchhydraulicReference
Rear PTO Type540 (1.375)Reference
Mid PTO Type2500Reference
Dimensions
Wheelbase166 cmReference
Weight1786 to 2293 poundsReference
Front tire7-12Reference
Rear tire12.4-16Reference
Standard tires (ag)Front: 7-12. Rear: 12.4-16Reference
Lawn/turf front24x8.50-14Reference
Lawn/turf rear13.6-16Reference
Industrial front23x8.50-14Reference
Industrial rear12.4-16Reference
Length257 cmReference
Width136 cmReference
Height (ROPS)224 cmReference
Height (cab)214 cmReference
Weight810 kgReference
Weight1040 kgReference
Ground clearance37 cmReference
Kubota B2650 attachments
60" mid-mount mower deckReference
72" mid-mount mower deckReference
front-end loaderReference
backhoeReference
Electrical
GroundnegativeReference
ROPS Charging systemdynamoReference
Cab Charging systemalternatorReference
ROPS Charging amps14.5Reference
Cab Charging amps40Reference
Battery CCA430Reference
Battery volts12Reference
Attachment overview
60" mid-mount mower deckReference
72" mid-mount mower deckReference
Front-end loaderReference
BackhoeReference
Kubota BH77 Backhoe
Backhoe typeKubota BH77 BackhoeReference
2-Foot flat digging depth233 cmReference
Reach from pivot316 cmReference
Loading height169 cmReference
Swing Arc180°Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
