Tractor · 2000Unverified

Kubota B2910

Name: Kubota B2910
Brand: Kubota

Kubota B2910 — B Series · 30 hp. Reference specifications; pending source verification.

The Kubota B2910 is a tractor model rated at approximately 30 hp, positioning it at the lower end of its class in terms of power output. Manufactured from 2000 to 2005, this model features a 4-cylinder diesel liquid-cooled engine and four-wheel drive, paired with a hydrostatic transmission. Its operating weight is listed as 799 kg, and it is suitable for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

30 hp

Weight

799 kg

Catalogue coverage

Variants represented

Richest spec table

126 rows

Recorded power

30 hp

Recorded weight

799 kg

Transmissions

hydrostatic

Production years

2000-2005

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Compact Utility tractorReference

Four-wheel driveReference

Final drivesspur gearReference

Differential lockmechanical rearReference

Power steeringReference

Wet disc brakesReference

Two-post folding ROPS.Reference

Variants

B2910deluxeReference

B7800economyReference

Engine

Kubota 1.5L 4-cyl dieselReference

Fuel tank26.1 LReference

Engine (gross)22.4 kWReference

Kubota V1505-E-D16Reference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement1.5 LReference

Bore/Stroke78 x 78 mmReference

Power (gross)22.4 kWReference

Air cleanerdryReference

Rated RPM2600Reference

Starter volts12Reference

Oil capacity4.1 LReference

Coolant capacity4.4 LReference

Fuel TypeDieselReference

No of Cylinders4 cylinderReference

Bore and stroke3.07x3.09 inchesReference

Cooling systemliquid-cooledReference

Transmission

hydrostaticReference

TypehydrostaticReference

Gearsinfinite forward and reverse (3-range)Reference

Oil capacity14.5 LReference

The B2910 features a cruise control lever to the right of the seat.Reference

Transmission TypeHSTReference

forward and reverse optionsinfinite forward and infinite reverse (3-range)Reference

Rear Axle Drive Typespur gearReference

PTO & Hydraulics

PTO (claimed)16.4 kWReference

Typeopen centerReference

Valves2Reference

Pump flow24.2 lpmReference

Total flow36.0 lpmReference

Steering flow11.7 lpmReference

Rear TypeIReference

Controlposition controlReference

Rear lift (at ends)750 kgReference

Rear lift (at 24"/610mm)589 kgReference

Rear PTOliveReference

Rear PTO Type540 (1.375)Reference

Engine RPM540@2600Reference

Mid PTOliveReference

Mid PTO Type2500 (Kubota 10-spline)Reference

Engine RPM2500@2578Reference

Dimensions

Wheelbase166 cmReference

Weight799 kgReference

Front tire7-12Reference

Rear tire12.4-16Reference

Weight383 kgReference

Weight403 kgReference

Ag front7-12Reference

Ag rear12.4-16Reference

Lawn/turf front24x8.50-14Reference

Lawn/turf rear13.6-16Reference

Industrial front23x8.50-14Reference

Industrial rear12.4-16Reference

Length251 cmReference

Width136 cmReference

Height (ROPS)199 cmReference

Ground clearance37 cmReference

Kubota B2910 attachments

60" mid-mount mower deckReference

72" mid-mount mower deckReference

snowblowerReference

bladeReference

front-end loaderReference

backhoeReference

Electrical

GroundnegativeReference

Battery CCA443Reference

Battery volts12Reference

Total cold cranking amps443 CCAReference

Attachment overview

60" mid-mount mower deckReference

72" mid-mount mower deckReference

SnowblowerReference

BladeReference

Front-end loaderReference

BackhoeReference

Kubota B4672A Backhoe

Backhoe typeKubota B4672A BackhoeReference

Transport height171 cmReference

Digging depth187 cmReference

Reach from pivot249 cmReference

Loading height165 cmReference

Bucket Rotation180°Reference

Swing Arc180°Reference

Bucket force1338 kgReference

Dipperstick force789 kgReference

Kubota BL4690A Backhoe

Backhoe typeKubota BL4690A BackhoeReference

Transport height193 cmReference

Digging depth229 cmReference

Reach from pivot295 cmReference

Loading height200 cmReference

Bucket Rotation180°Reference

Swing Arc180°Reference

Bucket force1338 kgReference

Dipperstick force789 kgReference

Speeds

With 12.4-16 R1 rear tires.Reference

General

Make & ModelKubotaReference

Rollover protective structureTwo-post folding ROPSReference

Capacities

Capacity91.5 ciReference

Crankcase oil volume4.3 qtsReference

PTO

Rear PTO PowerAvailableReference

Rear PTO RPM540 RPMReference

Mid PTO RPM2,500 RPMReference

Engine Speed on Mid PTO speed2,500@2,578 RPMReference

Engine Speed on Rear PTO speed540@2,600 RPMReference

Steering & brakes

BrakesWet discReference

Steering typePower steeringReference

Hydraulics

Hydraulics Typeopen centerReference

Remote Valves2 ValvesReference

Steering & Implements flow3.1 gpm (6.4 gpm)Reference

Rear Hitch category (SAE designation)Category IReference

Rear Hitch Sensing Typeposition controlReference

Dimensions & weight

Height Over ROPS199.4 cmReference

Overall Length252 cmReference

Overall Width136.7 cmReference

Wheels & tyres

Rear Wheel Type12.4-16Reference

Front Wheel Type7-12Reference

Operator station

Seat SuspensionTRUEReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
