Tractor · 2000Unverified
Kubota B2910
Kubota B2910 — B Series · 30 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
30 hp
Weight
799 kg
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Compact Utility tractorReference
Four-wheel driveReference
Final drivesspur gearReference
Differential lockmechanical rearReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS.Reference
Variants
B2910deluxeReference
B7800economyReference
Engine
Kubota 1.5L 4-cyl dieselReference
Fuel tank26.1 LReference
Engine (gross)22.4 kWReference
Kubota V1505-E-D16Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement1.5 LReference
Bore/Stroke78 x 78 mmReference
Power (gross)22.4 kWReference
Air cleanerdryReference
Rated RPM2600Reference
Starter volts12Reference
Oil capacity4.1 LReference
Coolant capacity4.4 LReference
Transmission
hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverse (3-range)Reference
Oil capacity14.5 LReference
The B2910 features a cruise control lever to the right of the seat.Reference
PTO & Hydraulics
PTO (claimed)16.4 kWReference
Typeopen centerReference
Valves2Reference
Pump flow24.2 lpmReference
Total flow36.0 lpmReference
Steering flow11.7 lpmReference
Rear TypeIReference
Controlposition controlReference
Rear lift (at ends)750 kgReference
Rear lift (at 24"/610mm)589 kgReference
Rear PTOliveReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@2600Reference
Mid PTOliveReference
Mid PTO Type2500 (Kubota 10-spline)Reference
Engine RPM2500@2578Reference
Dimensions
Wheelbase166 cmReference
Weight799 kgReference
Front tire7-12Reference
Rear tire12.4-16Reference
Weight383 kgReference
Weight403 kgReference
Ag front7-12Reference
Ag rear12.4-16Reference
Lawn/turf front24x8.50-14Reference
Lawn/turf rear13.6-16Reference
Industrial front23x8.50-14Reference
Industrial rear12.4-16Reference
Length251 cmReference
Width136 cmReference
Height (ROPS)199 cmReference
Ground clearance37 cmReference
Kubota B2910 attachments
60" mid-mount mower deckReference
72" mid-mount mower deckReference
snowblowerReference
bladeReference
front-end loaderReference
backhoeReference
Electrical
GroundnegativeReference
Battery CCA443Reference
Battery volts12Reference
Attachment overview
60" mid-mount mower deckReference
72" mid-mount mower deckReference
SnowblowerReference
BladeReference
Front-end loaderReference
BackhoeReference
Kubota B4672A Backhoe
Backhoe typeKubota B4672A BackhoeReference
Transport height171 cmReference
Digging depth187 cmReference
Reach from pivot249 cmReference
Loading height165 cmReference
Bucket Rotation180°Reference
Swing Arc180°Reference
Bucket force1338 kgReference
Dipperstick force789 kgReference
Kubota BL4690A Backhoe
Backhoe typeKubota BL4690A BackhoeReference
Transport height193 cmReference
Digging depth229 cmReference
Reach from pivot295 cmReference
Loading height200 cmReference
Bucket Rotation180°Reference
Swing Arc180°Reference
Bucket force1338 kgReference
Dipperstick force789 kgReference
Speeds
With 12.4-16 R1 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
