Tractor · 2010Unverified
Kubota B3300SU
Kubota B3300SU — Compact Utility tractor · 33 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
33 hp
Weight
875 kg
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Compact Utility tractorReference
Original price$18,580 (2011)Reference
Four-wheel driveReference
Differential lockrear standardReference
SteeringpowerReference
Wet disc brakesReference
Two-post ROPS. Optional sunshade.Reference
Engine
Kubota 1.5L 4-cyl dieselReference
Fuel tank30.7 LReference
Engine (gross)24.6 kWReference
Kubota V1505-E3-D24HReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement1.5 LReference
Bore/Stroke79 x 79 mmReference
Power (gross)24.6 kWReference
Air cleanerdual paper elementReference
Rated RPM2700Reference
Starter volts12Reference
Oil capacity5.4 LReference
Coolant capacity4.4 LReference
Transmission
hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverse (3-range)Reference
Clutchdry plateReference
Oil capacity14.5 LReference
PTO & Hydraulics
PTO (claimed)18.6 kWReference
Typeopen centerReference
Rear valves0 or 1Reference
Pump flow25.4 lpmReference
Total flow37.5 lpmReference
Steering flow12.1 lpmReference
Rear TypeIReference
Rear lift (at ends)810 kgReference
Rear lift (at 24"/610mm)635 kgReference
Rear PTOliveReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@2600Reference
Dimensions
Wheelbase169 cmReference
Weight875 kgReference
Front tire7-12Reference
Rear tire12.4-16Reference
Ag front7-12Reference
Ag rear12.4-16Reference
Industrial front25x8.5-14Reference
Industrial rear15-19.5Reference
Length251 cmReference
Width136 cmReference
Ground clearance37 cmReference
Kubota B3300SU attachments
front-end loaderReference
backhoeReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps14.5Reference
Charging amps40 (optional)Reference
Battery volts12Reference
Battery AH36Reference
Attachment overview
Front-end loaderReference
BackhoeReference
The Kubota B3300SU was sold standard as a loader-tractor and a backhoe was optional. Additional Kubota-specified attachments included 51 or 64-inch rear snow blowers, 60 or 72-inch front blades, and 40 or 50-inch rear tillers.Reference
Kubota BH76 Backhoe
Backhoe typeKubota BH76 BackhoeReference
Digging depth234 cmReference
2-Foot flat digging depth231 cmReference
8-Foot flat digging depth176 cmReference
Reach from pivot306 cmReference
Loading height163 cmReference
Bucket force1514 kgReference
Dipperstick force951 kgReference
Speeds
With 12.4-16 R1 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
