Tractor · 2013Unverified

Kubota B3350

Name: Kubota B3350
Brand: Kubota

Kubota B3350 — B50 Series · 33 hp. Reference specifications; pending source verification.

The Kubota B3350 is a compact tractor with a rating of 33 hp, manufactured in 2013. It features a 4-cylinder turbocharged diesel liquid-cooled engine, which drives through a four-wheel drive system with a hydrostatic transmission. The tractor's listed weight ranges from 1896 to 2447 pounds, and it is designed for tasks on plots of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

33 hp

Max power

33 hp

Weight

1896 to 2447 pounds

Catalogue coverage

Variants represented

Richest spec table

125 rows

Recorded power

33 hp

Recorded weight

860 kg

Transmissions

hydrostatic

Production years

2013-2013

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Compact Utility tractorReference

Original price$21,242 (2014 ROPS )Reference

Original price$28,865 (2014 Cab )Reference

Four-wheel driveReference

Final drivesspur gearReference

Differential lockstandardReference

Steeringhydrostatic powerReference

Wet disc brakesReference

Two-post foldable ROPS. Cab optional with air-conditioning.Reference

Variants

B3350HSDROPSReference

B3350HSDCCabReference

B3350SUHSDspecial utilityReference

Engine

Kubota 1.5L 4-cyl dieselReference

Fuel tank27.6 LReference

Engine (gross)24.6 kWReference

Kubota V1505Reference

turbocharged dieselReference

4-cylinderReference

liquid-cooledReference

Displacement1.5 LReference

Bore/Stroke79 x 79 mmReference

EmissionsTier IVReference

Emission controldiesel particulate filter (DPF)Reference

Power (gross)24.6 kWReference

Air cleanerdual paper elementsReference

Rated RPM2500Reference

StarterelectricReference

Starter volts12Reference

Oil capacity4.8 LReference

Coolant capacity4.3 LReference

Fuel TypedieselReference

No of Cylinders4 cylinderReference

Rated engine speed2,500 RPMReference

Emissions complianceTier IV | diesel particulate filter (DPF)Reference

Bore and stroke3.1x3.1 inchesReference

Cooling systemliquid-cooledReference

Transmission

hydrostaticReference

TypehydrostaticReference

Gearsinfinite forward and reverse (3-range)Reference

Oil capacity15.1 LReference

Transmission TypeHSTReference

forward and reverse optionshydrostatic : infinite (3-range) forward and reverseReference

Wheel Drive4WDReference

Rear Axle Drive Typespur gearReference

PTO & Hydraulics

PTO (claimed)20.1 kWReference

Typeopen centerReference

Valves1Reference

Pump flow18.9 lpmReference

Total flow32.9 lpmReference

Steering flow14.0 lpmReference

Rear TypeIReference

Controlposition controlReference

Rear lift (at ends)970 kgReference

Rear lift (at 24"/610mm)760 kgReference

Rear PTOindependentReference

ClutchhydraulicReference

Rear PTO Type540 (1.375)Reference

Mid PTO Type2500Reference

Dimensions

Wheelbase166 cmReference

Weight1896 to 2447 poundsReference

Front tire7-12Reference

Rear tire12.4-16Reference

Standard tires (ag)Front: 7-12. Rear: 12.4-16Reference

Lawn/turf front24x8.50-14Reference

Lawn/turf rear13.6-16Reference

Industrial front23x8.50-14Reference

Industrial front25x8.50-14Reference

Industrial rear12.4-16Reference

Industrial rear15-19.5Reference

Length257 cmReference

Width136 cmReference

Height (ROPS)224 cmReference

Height (cab)214 cmReference

Weight860 kgReference

Weight1109 kgReference

Ground clearance37 cmReference

Kubota B3350 attachments

60" mid-mount mower deckReference

72" mid-mount mower deckReference

front-end loaderReference

backhoeReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps60Reference

Battery CCA430Reference

Battery volts12Reference

Total cold cranking amps430 CCAReference

Attachment overview

60" mid-mount mower deckReference

72" mid-mount mower deckReference

Front-end loaderReference

BackhoeReference

Kubota BH77 Backhoe

Backhoe typeKubota BH77 BackhoeReference

2-Foot flat digging depth233 cmReference

Reach from pivot316 cmReference

Loading height169 cmReference

Swing Arc180°Reference

General

Make & ModelKubotaReference

SCV controljoystickReference

Rollover protective structureTwo-post foldable ROPS.Reference

Capacities

Capacity91.5 ciReference

Crankcase oil volume5.1 qtsReference

Power

Max Power33 hpReference

PTO

PTO Power27 hpReference

Rear PTO PowerAvailableReference

Rear PTO RPM540 RPMReference

Mid PTOAvailableReference

Mid PTO RPM2,500 RPMReference

Steering & brakes

Brakeswet discReference

Steering typehydrostatic powerReference

Hydraulics

Pump Rated Output (total)8.7 gpmReference

Hydraulics Typeopen centerReference

Remote Valves1 valveReference

Steering & Implements flow3.7 gpm (5 gpm)Reference

Rear Hitch category (SAE designation)Category IReference

Rear Hitch maximum lift capacity970.2 kgReference

Rear Hitch Sensing Typeposition controlReference

Dimensions & weight

Height Over ROPS224.5 cmReference

Height Over Cab214.9 cmReference

Overall Length257 cmReference

Overall Width136.4 cmReference

Overall weight860 kgReference

Wheels & tyres

Rear Wheel Type12.4-16Reference

Front Wheel Type45,485Reference

Operator station

Cab AvailabilityAvailableReference

Seat SuspensionTRUEReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
