Tractor · 1988Unverified
Kubota B40
Kubota B40 — Sub-Compact Utility tractor · 14 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
14 hp
Weight
550 kg
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Sub-Compact Utility tractorReference
Four-wheel driveReference
Open operator station.Reference
Engine
Kubota 0.9L 3-cyl dieselReference
Fuel tank17.0 LReference
Engine10.4 kWReference
Kubota D850Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement0.9 LReference
Bore/Stroke72 x 70 mmReference
Power10.4 kWReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
6-speed gearReference
TypegearReference
Gears6 forward and 2 reverseReference
PTO & Hydraulics
Rear TypeJIS0Reference
Rear PTO Type540 (1.375)Reference
Engine RPM447@2600Reference
Engine RPM814@2600Reference
Engine RPM1228@2600Reference
Dimensions
Wheelbase124 cmReference
Weight550 kgReference
Front tire5.00-12Reference
Rear tire8-16Reference
Standard tires (ag)Front: 5.00-12. Rear: 8-16Reference
Length215 cmReference
Width105 cmReference
Height124 cmReference
Ground clearance23 cmReference
Front tread76 cmReference
Rear tread81/89 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
