Tractor · 1983Unverified
Kubota B5200
Kubota B5200 — B Series · 13 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
13 hp
Weight
1058 to 1180 pounds
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Built in JapanReference
Original price was $8,250 in 1990 with 4WDReference
Two- or four-wheel driveReference
Manual steeringReference
Dry internal expanding brakesReference
Two-post ROPS.Reference
Variants
B5200E2WDReference
B5200D4WDReference
Engine
Kubota 0.8L 3-cyl dieselReference
Engine (gross)9.7 kWReference
Plows1Reference
Kubota D750Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement0.8 LReference
Bore/Stroke68 x 70 mmReference
Power (gross)9.7 kWReference
Air cleanerdryReference
Rated RPM2500Reference
Starter volts12Reference
Oil capacity3.4 LReference
Coolant capacity4.6 LReference
Transmission
6-speed gearReference
TypegearReference
Gears6 forward and 2 reverseReference
Clutchdry plateReference
Oil capacity12.0 LReference
Three gears (1-3) plus reverse with high and low ranges.Reference
PTO & Hydraulics
PTO (claimed)8.6 kWReference
Hydraulic system12.1 LReference
Typeopen centerReference
Capacity12.1 LReference
Pressure112.4 barReference
Total flow15.1 lpmReference
Rear TypeIReference
Rear lift469 kgReference
Rear PTOtransmissionReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@2370Reference
Engine RPM825@2370Reference
Front PTOoptionalReference
Front PTO Type2500Reference
Capacities
Fuel14.4 LReference
Dimensions
Wheelbase139 cmReference
Weight1058 to 1180 poundsReference
Front tire4.5-10Reference
Rear tire7-16Reference
Weight99 kgReference
Ag front4.5-10 (2WD)Reference
Ag front5.00-10 (2WD)Reference
Ag front5-12 (4WD)Reference
Ag front6-12 (4WD)Reference
Ag rear7-16Reference
Ag rear8-16Reference
Lawn/turf front18x9.50-9 (2WD)Reference
Lawn/turf front20.5x8.00-10 (4WD)Reference
Lawn/turf rear29x12.00-15Reference
Length254 cmReference
Width107 cmReference
2WD Height (exhaust)179 cmReference
4WD Height (exhaust)181 cmReference
2WD Weight479 kgReference
4WD Weight535 kgReference
Ground clearance27 cmReference
2WD Front tread71 cmReference
4WD Front tread78 cmReference
Rear tread90 to 0 cmReference
Kubota B5200 attachments
48" mid-mount mower deckReference
snowblowerReference
front-end loaderReference
backhoeReference
B5200 Serial Numbers
198310003Reference
198411800Reference
198530003Reference
198648216Reference
198766409Reference
198874602Reference
198982795Reference
199090488Reference
199197681Reference
1992104372Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps35Reference
Battery volts12Reference
Attachment overview
48" mid-mount mower deckReference
SnowblowerReference
Kubota B1630C loaderReference
Kubota B1640 loaderReference
Kubota B1640A loaderReference
BackhoeReference
Attachments for the Kubota B5200 included a 46-inch rear finish mower (B3538), the 33.5-inch FL850 tiller, the B340 (48-inch) disc harrow, and a single-bottom 12-inch plow. The B2551 snowblower could be mounted on the front or rear.Reference
48" Mower deck
Typemid-mount Kubota RC48-62AReference
Type3-bladeReference
Cutting width121 cmReference
Overall width153 cmReference
Cut height3 to 10 cmReference
Kubota L4520 Backhoe
Backhoe typeKubota L4520 BackhoeReference
Transport height155 cmReference
Bucket width25 cmReference
Bucket width30 cmReference
Bucket width40 cmReference
2-Foot flat digging depth201 cmReference
Reach from pivot248 cmReference
Loading height213 cmReference
Bucket Rotation170°Reference
Swing Arc177°Reference
Bucket force657 kgReference
Dipperstick force1308 kgReference
Speeds
With 7-16 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
