Tractor · 1977Unverified
Kubota B7100HST
Kubota B7100HST — B Series · 16 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
16 hp
Weight
1151 to 1265 pounds
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Compact Utility tractorReference
Built in JapanReference
Two- or four-wheel driveReference
Differential lockmechanical rearReference
Manual steeringReference
Differential mechanical expanding shoe brakesReference
Open operator station. Two-post ROPS available.Reference
Variants
B7100HST-E2WD hydroReference
B7100HST-D4WD hydroReference
B7100HSD4WD hydroReference
B7100gear driveReference
Engine
Kubota 0.8L 3-cyl dieselReference
Engine (gross)11.9 kWReference
Kubota D750-AHReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement0.8 LReference
Bore/Stroke67 x 70 mmReference
Power (gross)11.9 kWReference
Air cleanerdryReference
Pre-heatingglow plugsReference
Rated RPM2800Reference
Torque43.1 NmReference
Torque RPM1800Reference
Starter volts12Reference
Starter power0.8 kWReference
Coolant capacity4.6 LReference
Oil capacity3.1 LReference
Oil change75 hReference
Transmission
hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverse (2-range)Reference
Oil capacity13.4 LReference
PTO & Hydraulics
PTO (claimed)9.7 kWReference
Hydraulic system13.6 LReference
Typeopen centerReference
Capacity13.6 LReference
Pump flow11.4 lpmReference
Rear TypeIReference
Rear PTO Type540/850 (1.375)Reference
Engine RPM540@2800Reference
Engine RPM850@2800Reference
Mid PTO Type2500 (Kubota 1x10)Reference
Engine RPM2450@2800Reference
Front PTO Type2800Reference
Capacities
Fuel12.9 LReference
Dimensions
4WD Wheelbase139 cmReference
2WD Wheelbase138 cmReference
Weight1151 to 1265 poundsReference
Front tire6.9-9Reference
2WD Rear tire8.3-16Reference
Weight340 kgReference
2WD Standard tires (ag)Front: 6.9-9. Rear: 8.3-16Reference
4WD Standard tires (ag)Front: 6-12. Rear: 8.3-16Reference
Lawn/turf front20.5-8.00x10Reference
Lawn/turf rear29-12.00x15Reference
Length212 cmReference
Width101 cmReference
2WD Height (steering wheel)117 cmReference
4WD Height (steering wheel)118 cmReference
4WD Weight573 kgReference
2WD Weight522 kgReference
2WD Ground clearance25 cmReference
4WD Ground clearance24 cmReference
2WD Front tread69 cmReference
4WD Front tread85 cmReference
Rear tread66/70/75 cmReference
Kubota B7100HST attachments
48" mid-mount mower deckReference
60" mid-mount mower deckReference
bladeReference
front-end loaderReference
backhoeReference
B7100HST Serial Numbers
Location:Clutch housing, left sideReference
198010157Reference
198111035Reference
198213305Reference
198351426Reference
198453433Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Battery volts12Reference
Battery AH45Reference
Attachment overview
48" mid-mount mower deckReference
60" mid-mount mower deckReference
BladeReference
Front-end loaderReference
BackhoeReference
Kubota B670 Backhoe
Backhoe typeKubota B670 BackhoeReference
Transport height154 cmReference
Bucket width22 cmReference
Bucket width33 cmReference
Bucket width40 cmReference
2-Foot flat digging depth185 cmReference
Reach from pivot254 cmReference
Loading height152 cmReference
Bucket Rotation180°Reference
Swing Arc180°Reference
Bucket force1088 kgReference
Speeds
With 8-16 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
