Tractor · 2004Unverified

Kubota B7510

Kubota B7510 — B7x10 Series · 21 hp. Reference specifications; pending source verification.

The Kubota B7510 is a compact tractor model, rated at 21 horsepower, which places it among the smaller options in its class. It was manufactured from 2004 to 2007. The tractor features a 3-cylinder diesel liquid-cooled engine, coupled with a hydrostatic transmission and four-wheel drive. Its listed operating weight is between 1323 and 1367 pounds, suitable for tasks involving around 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power
21 hp
Weight
1323 to 1367 pounds

Catalogue coverage

Variants represented
2
Richest spec table
133 rows
Recorded power
21 hp
Recorded weight
383 kg
Transmissions
hydrostatic
Production years
2004-2007
Verified variants
0

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference
Compact Utility tractorReference
Four-wheel driveReference
Final drivesspur gearReference
Differential lockmechanical rearReference
Steeringpower assistReference
Wet disc brakesReference
Two-post folding ROPS.Reference

Variants

B7510DTgearReference
B7510DTNnarrowReference
B7510HSDhydrostaticReference

Engine

Kubota 1.0L 3-cyl dieselReference
Fuel tank20.1 LReference
Engine (gross)15.7 kWReference
Kubota D1005-E2-D16Reference
dieselReference
3-cylinderReference
liquid-cooled inlineReference
Displacement1.0 LReference
Bore/Stroke76 x 74 mmReference
Power (gross)15.7 kWReference
Air cleanerdual paper elementReference
Rated RPM2600Reference
Torque59.7 NmReference
Starter volts12Reference
Oil capacity3.0 LReference
Coolant capacity3.8 LReference
Fuel TypeDieselReference
No of Cylinders3 CylinderReference
Rated engine speed2,600 RPMReference
Engine torque at rated speed20 kgReference
Bore and stroke2.992x2.898 inchesReference
Cooling systemliquid-cooledReference

Transmission

hydrostaticReference
6-speed gearReference
Gear Weight600 kgReference
TypehydrostaticReference
Gearsinfinite forward and reverse (2-range)Reference
Oil capacity15.3 LReference
TypegearReference
Gears6 forward and 2 reverseReference
Clutchdry discReference
Oil capacity13.5 LReference
Transmission TypeHSTReference

PTO & Hydraulics

Gear PTO (claimed)12.7 kWReference
Hydro PTO (claimed)11.9 kWReference
Typeopen centerReference
Valves1Reference
Valves2 (DTN)Reference
Pump flow16.7 lpmReference
Total flow26.5 lpmReference
Steering flow9.8 lpmReference
Rear TypeIReference
Controlquarter inching valveReference
Controlposition control (DTN)Reference
Rear lift (at ends)615 kgReference
Rear lift (at ends)750 kgReference
Rear lift (at 24"/610mm)479 kgReference
Rear lift (at 24"/610mm)750 kgReference
Gear Rear PTOtransmissionReference
Hydro Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Engine RPM540Reference
Engine RPM960Reference
Mid PTO Type2500Reference

Dimensions

Wheelbase150 cmReference
Weight1323 to 1367 poundsReference
Front tire6-12Reference
Rear tire9.5-16Reference
Weight383 kgReference
Standard tires (ag)Front: 6-12. Rear: 9.5-16Reference
Standard tires (ag)Front: 5-12. Rear: 8-16 (DTN)Reference
Length230 cmReference
DTN Length227 cmReference
Width107 cmReference
DTN Width89 cmReference
Hydro Weight620 kgReference
Ground clearance30 cmReference
DTN Ground clearance29 cmReference
Steering wheel132 cmReference
DTN Steering wheel130 cmReference

Kubota B7510 attachments

54" mid-mount mower deckReference
mid-mount mower deckReference
snowblowerReference
bladeReference
front-end loaderReference
backhoeReference

Electrical

GroundnegativeReference
Battery CCA433Reference
Battery volts12Reference
Total cold cranking amps433Reference

Attachment overview

54" mid-mount mower deckReference
Mid-mount mower deckReference
SnowblowerReference
BladeReference
Front-end loaderReference
BackhoeReference

Kubota B4672 Backhoe

Backhoe typeKubota B4672 BackhoeReference
Transport height171 cmReference
Bucket width25 cmReference
Bucket width30 cmReference
Bucket width40 cmReference
Bucket width60 cmReference
Digging depth187 cmReference
Reach from pivot249 cmReference
Loading height165 cmReference
Bucket Rotation180°Reference
Swing Arc180°Reference
Bucket force1338 kgReference
Dipperstick force789 kgReference

Kubota B7510 Height

ROPS194 cmReference
DTN ROPS191 cmReference

General

Make & ModelKubotaReference
Rollover protective structureTwo-post ROPSReference

Capacities

Capacity61.1 ciReference
Crankcase oil volume3.2 qtsReference

PTO

Rear PTO PowerAvailableReference
Rear PTO RPM960 RPMReference
Mid PTOAvailableReference
Mid PTO RPM2,500 RPMReference

Steering & brakes

Brakeswet discReference
Steering typepower assistReference

Hydraulics

Hydraulics Typeopen centerReference
Remote Valves1 valvesReference
Steering & Implements flow2.6 gpm (4.4 gpm)Reference
Rear Hitch category (SAE designation)Category IReference
Rear Hitch maximum lift capacity615.1 kgReference
Rear Hitch Sensing Typequarter inching valve | position control (DTN)Reference

Dimensions & weight

Height Over ROPS194.1 cmReference
Overall Length230.1 cmReference
Overall Width107.7 cmReference

Wheels & tyres

Rear Wheel TypeStandard tires (ag) : Rear: 9.5-16Reference
Front Wheel TypeStandard tires (ag)\\tFront: 6-12.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
