Tractor · 2004Unverified
Kubota B7610
Kubota B7610 — B7x10 Series · 24 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
24 hp
Weight
620 kg
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Compact Utility tractorReference
Four-wheel driveReference
Final drivesspur gearReference
Differential lockmechanical rearReference
Steeringpower assistReference
Wet disc brakesReference
Two-post ROPS.Reference
Engine
Kubota 1.1L 3-cyl dieselReference
Fuel tank20.1 LReference
Engine (gross)17.9 kWReference
Kubota D1105-E-D16Reference
dieselReference
3-cylinderReference
liquid-cooled inlineReference
Displacement1.1 LReference
Bore/Stroke78 x 78 mmReference
Power (gross)17.9 kWReference
Air cleanerdual paper elementReference
Rated RPM2600Reference
Torque67.8 NmReference
Starter volts12Reference
Oil capacity3.0 LReference
Coolant capacity3.8 LReference
Transmission
hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverse (2-range)Reference
Oil capacity15.3 LReference
PTO & Hydraulics
PTO (claimed)13.4 kWReference
Typeopen centerReference
Valves1Reference
Pump flow16.7 lpmReference
Total flow26.5 lpmReference
Steering flow9.8 lpmReference
Rear TypeIReference
Controlquarter inching valveReference
Rear lift (at ends)615 kgReference
Rear lift (at 24"/610mm)615 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Engine RPM540Reference
Engine RPM960Reference
Mid PTO Type2500Reference
Dimensions
Wheelbase150 cmReference
Weight620 kgReference
Front tire7-12Reference
Rear tire11.2-16Reference
Weight383 kgReference
Ag front7-12Reference
Ag rear11.2-16Reference
Length232 cmReference
Width117 cmReference
Height (steering wheel)135 cmReference
Height (ROPS)196 cmReference
Ground clearance32 cmReference
Kubota B7610 attachments
54" mid-mount mower deckReference
mid-mount mower deckReference
bladeReference
front-end loaderReference
backhoeReference
Electrical
GroundnegativeReference
Battery CCA433Reference
Battery volts12Reference
Attachment overview
54" mid-mount mower deckReference
Mid-mount mower deckReference
BladeReference
Front-end loaderReference
BackhoeReference
Kubota B4672 Backhoe
Backhoe typeKubota B4672 BackhoeReference
Transport height171 cmReference
Bucket width25 cmReference
Bucket width30 cmReference
Bucket width40 cmReference
Bucket width60 cmReference
Digging depth187 cmReference
Reach from pivot249 cmReference
Loading height165 cmReference
Bucket Rotation180°Reference
Swing Arc180°Reference
Bucket force1338 kgReference
Dipperstick force789 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
