Tractor · 1983Unverified
Kubota B8200
Kubota B8200 — Compact Utility tractor · 19 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
19 hp
Weight
1420 to 1698 pounds
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Compact Utility tractorReference
Built in JapanReference
Original price$11,400 (1990 B8200HST-D)Reference
Two- or four-wheel driveReference
Differential lockmechanical rearReference
SteeringmanualReference
SteeringpowerReference
Dry internal expanding brakesReference
Two-post ROPS.Reference
Variants
B8200F2WD gearReference
B8200DT4WD gearReference
B8200E2WD gearReference
B8200D4WD gearReference
B8200HST-E2WD hydroReference
B8200HST-D4WD hydroReference
Engine
Kubota 0.9L 3-cyl dieselReference
Engine (gross)14.2 kWReference
Plows1Reference
Kubota D950-A-DTReference
dieselReference
3-cylinderReference
liquid-cooled inlineReference
Displacement0.9 LReference
Bore/Stroke75 x 70 mmReference
Power (gross)14.2 kWReference
Air cleanerdry paper elementReference
Rated RPM2600Reference
Starter volts12Reference
Oil capacity3.1 LReference
Coolant capacity4.0 LReference
Transmission
hydrostaticReference
9-speed gearReference
2WD gear644 kgReference
4WD gear709 kgReference
TypehydrostaticReference
Gearsinfinite forward and reverse (3-range)Reference
Oil capacity18.0 LReference
TypegearReference
Gears9 forward and 3 reverseReference
Clutch7.9-inch dry discReference
Three gears (1-3) plus reverse in three ranges (L-M-H).Reference
PTO & Hydraulics
Gear PTO (claimed)11.9 kWReference
Hydro PTO (claimed)10.8 kWReference
Hydraulic system18.2 LReference
Typeopen centerReference
Capacity18.2 LReference
Pressure118.2 barReference
Total flow15.1 lpmReference
Total flow22.7 lpmReference
Total flow24.6 lpmReference
Rear TypeIReference
Controlposition controlReference
Rear lift (at ends)580 kgReference
Rear lift (at 24"/610mm)460 kgReference
Rear PTOliveReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@2534Reference
Engine RPM748@2534Reference
Mid PTOindependent (hydro)Reference
Mid PTO Type31/32 10-splineReference
Engine RPM1745@2534Reference
Engine RPM2416@2534Reference
Front PTOcontinuousReference
Front PTO TypepulleyReference
Engine RPM2600@2600Reference
Capacities
Fuel20.1 LReference
Dimensions
Wheelbase153 cmReference
Weight1420 to 1698 poundsReference
Front tire4.00-12Reference
Rear tire8.3-24 (2WD)Reference
Standard tires (ag)Front: 4.00-12. Rear: 8.3-24 (2WD)Reference
Standard tires (ag)Front: 6-12. Rear: 12.4-16 (4WD)Reference
Optional tires (ag)Front: 6.50-10. Rear: 12.4-16 (2WD)Reference
Optional tires (ag)Front: 6-12. Rear: 8.3-24 (4WD)Reference
Lawn/turf front24x8.5-12Reference
Lawn/turf rear13.6-16Reference
Length271 cmReference
Width140 cmReference
Height (exhaust)202 cmReference
Ground clearance23 cmReference
Front tread83 cmReference
Front tread89 cmReference
Rear tread104 cmReference
2WD hydro717 kgReference
4WD hydro770 kgReference
Kubota B8200 attachments
60" mid-mount mower deckReference
snowblowerReference
front-end loaderReference
backhoeReference
B8200 Serial Numbers
Location:Left side of transmissionReference
Electrical
Charging systemalternatorReference
Charging amps35Reference
Battery volts12Reference
Attachment overview
60" mid-mount mower deckReference
SnowblowerReference
Front-end loaderReference
BackhoeReference
Factory attachments for the Kubota B8200 include a loader, backhoe, and several mowers. The RCB-60-1 mid-mount mower has a front PTO drive for gear models while the RC-82H has a mid PTO drive for hydrostatic model B8200 tractors. Tillage attachments matched by Kubota included a five-foot tandem disc harrow (L658), a single-bottom 14-inch plow (L201), and the 40-inch FL1020 rotary tiller.Reference
Kubota BK4520 Backhoe
Backhoe typeKubota BK4520 BackhoeReference
Digging depth198 cmReference
Reach from pivot240 cmReference
Kubota BL4520 Backhoe
Backhoe typeKubota BL4520 BackhoeReference
Transport height155 cmReference
Bucket width25 cmReference
Bucket width30 cmReference
Bucket width40 cmReference
2-Foot flat digging depth201 cmReference
Reach from pivot248 cmReference
Loading height213 cmReference
Bucket Rotation170°Reference
Swing Arc177°Reference
Bucket force657 kgReference
Dipperstick force1308 kgReference
Kubota BL4590 Backhoe
Backhoe typeKubota BL4590 BackhoeReference
Transport height200 cmReference
Bucket width33 cmReference
Bucket width45 cmReference
Bucket width60 cmReference
Bucket width76 cmReference
Bucket width91 cmReference
Digging depth229 cmReference
Reach from pivot295 cmReference
Loading height200 cmReference
Bucket Rotation180°Reference
Swing Arc180°Reference
Bucket force1338 kgReference
Dipperstick force789 kgReference
Speeds
With 8.3-24 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
