The Kubota Bb260 is a tractor rated at approximately 26 hp, placing it at the lighter end of its class. It is powered by a 4-cylinder diesel liquid-cooled engine, coupled with four-wheel drive and a 9-speed gearbox. The tractor has an operating weight of 964 kg and is suitable for operations covering up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
26 hp
Weight
964 kg
Catalogue coverage
Variants represented
2
Richest spec table
38 rows
Recorded power
26 hp
Recorded weight
964 kg
Transmissions
9-speed
Verified variants
0
1 linked source document displayed
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Compact Utility tractorReference
Four-wheel driveReference
Power steeringReference
Mechanical wet disc brakesReference
Cab standard.Reference
Engine
Kubota 1.5L 4-cyl dieselReference
Fuel tank20.1 LReference
Engine19.1 kWReference
Kubota V1505Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement1.5 LReference
Bore/Stroke78 x 78 mmReference
Power19.1 kWReference
Rated RPM2600Reference
StarternegativeReference
Starter volts12Reference
Transmission
9-speedReference
TransmissionGlideshiftReference
Gears9 forward and 3 reverseReference
PTO & Hydraulics
Rear TypeIReference
Controlposition controlReference
Rear PTO Type442/754/1192 (1.375)Reference
Dimensions
Wheelbase141 cmReference
Weight964 kgReference
Front tire6-14Reference
Rear tire9.5-20Reference
Standard tires (ag)Front: 6-14. Rear: 9.5-20Reference
Length249 cmReference
Width119 cmReference
Height (cab)172 cmReference
Ground clearance33 cmReference
Front tread86 cmReference
Rear tread94 cmReference
Electrical
GroundelectricReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
