Tractor · 2001Unverified

Kubota BX2200

Name: Kubota BX2200
Brand: Kubota

Kubota BX2200 — BX Series · 22 hp. Reference specifications; pending source verification.

The Kubota BX2200 is a tractor with a rated power of 22 hp, categorising it within the lighter end of its class. Built from 2001 to 2003, this model utilises a 3-cylinder diesel liquid-cooled engine, coupled with four-wheel drive and a hydrostatic transmission. Its operating weight is listed at 725 kg, and it is suited for operations of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

22 hp

Weight

725 kg

Catalogue coverage

Variants represented

Richest spec table

75 rows

Recorded power

22 hp

Recorded weight

725 kg

Transmissions

hydrostatic

Production years

2001-2003

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Sub-Compact Utility tractorReference

Four-wheel driveReference

Power steeringReference

Wet disc brakesReference

Two-post ROPS.Reference

Variants

BX22backhoe tractorReference

Engine

Kubota 0.9L 3-cyl dieselReference

Fuel tank20.8 LReference

Engine (gross)16.4 kWReference

Kubota D905 E-TVCSReference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement0.9 LReference

Bore/Stroke72 x 74 mmReference

Power (gross)16.4 kWReference

Fuel systemindirect injectionReference

Rated RPM3600Reference

Starter volts12Reference

Image courtesy of White's Farm SupplyReference

Fuel TypeDieselReference

No of Cylinders3 cylinderReference

Rated engine speed3,600 RPMReference

Bore and stroke2.83x2.90 inchesReference

Cooling systemliquid-cooledReference

Transmission

hydrostaticReference

TypehydrostaticReference

Gearsinfinite forward and reverse (2-range)Reference

Transmission TypeHSTReference

forward and reverse optionsinfinite forward and nfinite reverse (2-range)Reference

PTO & Hydraulics

PTO (claimed)12.5 kWReference

Rear TypeIReference

Rear lift295 kgReference

Rear PTOindependentReference

ClutchhydraulicReference

Rear PTO Type540 (1.375)Reference

Mid PTOindependentReference

Mid PTO Type2500Reference

Dimensions

Wheelbase139 cmReference

Weight725 kgReference

Front tire18x8.5Reference

Rear tire26x12.0Reference

Ag front18x8.5Reference

Ag rear26x12.0Reference

Lawn/turf front18x8.5Reference

Lawn/turf rear26x12.0Reference

Length233 cmReference

Width114 cmReference

Ground clearance17 cmReference

Kubota BX2200 attachments

54" mid-mount mower deckReference

60" mid-mount mower deckReference

snowblowerReference

bladeReference

front-end loaderReference

Electrical

GroundnegativeReference

Battery volts12Reference

Attachment overview

54" mid-mount mower deckReference

60" mid-mount mower deckReference

SnowblowerReference

BladeReference

Front-end loaderReference

The Kubota BX2200 was advertised as compatible with two mid-mount mowers (54-inch and 60-inch), two front-mount blades, a two-stage snowblower, and front-end loader. Additional attachments include the BX2537 rotary sweeper, B40C (37-inch) rear tiller, 42- and 48-inch box scrapers, 48-inch rear blade, and 60-inch rear-mounted mower.Reference

General

Make & ModelKubotaReference

Rollover protective structureTwo-post ROPSReference

Capacities

Capacity54.8 ciReference

PTO

Rear PTO PowerAvailableReference

Steering & brakes

BrakesWet disc brakesReference

Steering typePower steeringReference

Hydraulics

Rear Hitch category (SAE designation)Category IReference

Rear Hitch maximum lift capacity295.7 kgReference

Dimensions & weight

Overall Length233.9 cmReference

Overall Width114.6 cmReference

Wheels & tyres

Rear Wheel Type26x12.0Reference

Front Wheel Type18x8.5Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
