Tractor · 2017Unverified

Kubota BX2380

Name: Kubota BX2380
Brand: Kubota

Kubota BX2380 — BX80 Series · 23 hp. Reference specifications; pending source verification.

The Kubota BX2380 is a compact tractor rated at approximately 23 hp, positioned at the lighter end of its class in terms of power output. This model was manufactured in 2017. It features a 3-cylinder diesel liquid-cooled engine and four-wheel drive with a hydrostatic transmission. Its operating weight is listed at 654 kg, with a maximum operational area of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

23 hp

Max power

21.6 hp (3,200 rpm)

Weight

654 kg

Catalogue coverage

Variants represented

Richest spec table

90 rows

Recorded power

23 hp

Recorded weight

654 kg

Transmissions

hydrostatic

Production years

2017-2017

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Compact Utility tractorReference

Original price was $11,926 in 2017Reference

Four-wheel driveReference

Power steeringReference

Wet disc brakesReference

Two-post foldable ROPS.Reference

Variants

BX2380utility tractorReference

BX23Sloader-backhoe tractorReference

Engine

Kubota 0.9L 3-cyl dieselReference

Fuel tank25.0 LReference

Engine (gross)17.2 kWReference

Engine (net)15.2 kWReference

Kubota D902Reference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement0.9 LReference

Bore/Stroke72 x 74 mmReference

EmissionsTier IVReference

Power (net)15.2 kWReference

Power (gross)17.2 kWReference

Rated RPM3200Reference

StarterelectricReference

Starter volts12Reference

Oil capacity3.3 LReference

Coolant capacity3.1 LReference

Fuel TypeDieselReference

Transmission

hydrostaticReference

TypehydrostaticReference

Gearsinfinite forward and reverse (2-range)Reference

Transmission TypeHSTReference

forward and reverse options2x2Reference

forward speed rangeOption 1: 13.5 kmph\\nOption 2: 12.5 kmphReference

reverse speed rangeOption 1: 10.5 kmph\\nOption 2: 9.5 kmphReference

Wheel Drive4WDReference

PTO & Hydraulics

PTO (claimed)13.2 kWReference

Pump flow23.5 lpmReference

Rear TypeIReference

Rear lift (at 24"/610mm)308 kgReference

Rear PTOindependentReference

Rear PTO Type540 (1.375)Reference

Mid PTO Type2500Reference

Dimensions

Wheelbase139 cmReference

Weight654 kgReference

Front tire18x8.5-10Reference

Rear tire26x12-12Reference

Standard tires (ag)Front: 18x8.5-10. Rear: 26x12-12Reference

Lawn/turf front18x8.5-10Reference

Lawn/turf rear26x12-12Reference

Length242 cmReference

Width114 cmReference

Height (ROPS)211 cmReference

Clearance (front axle)21 cmReference

Front tread92 cmReference

Rear tread81 cmReference

Kubota BX2380 attachments

48" mid-mount mower deckReference

54" mid-mount mower deckReference

60" mid-mount mower deckReference

front-end loaderReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Battery volts12Reference

Attachment overview

48" mid-mount mower deckReference

54" mid-mount mower deckReference

60" mid-mount mower deckReference

Front-end loaderReference

General

Make & ModelKubota D722 @ Kubota D902Reference

Cruise controlTRUEReference

Capacities

Capacity898 ccReference

Power

Max Power21.6 hp (3,200 rpm)Reference

PTO

PTO Power17.7 hpReference

Rear PTO PowerYESReference

Rear PTO RPM540Reference

Mid PTOYESReference

Mid PTO RPM2,500Reference

Steering & brakes

BrakesWet discReference

Steering typeHydrostatic power steeringReference

Hydraulics

Pump Rated Output (total)23.5 l/minReference

Rear Hitch category (SAE designation)Category 1Reference

Dimensions & weight

Height Over ROPSOption 1: 2,110 mm\\nOption 2: 2,080 mmReference

Overall Width1,145 mmReference

Front axle clearance213 mmReference

Turning radius2.3 mReference

Overall weight654.5 kgReference

Wheels & tyres

Rear Wheel TypeOption 1: 26x12-12\\nOption 2: 24x12-12Reference

Rear wheel tread range820 mmReference

Front Wheel Type16x7.5-8Reference

Front Wheel tread range930 mmReference

Operator station

Cab AvailabilityOptionalReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
