Backhoe Loader · 2017Unverified

Kubota BX23S

Name: Kubota BX23S
Brand: Kubota

Kubota BX23S — BX80 Series · 23 hp. Reference specifications; pending source verification.

The Kubota BX23S is a backhoe loader rated at roughly 23 hp, which places it at the lighter end of its class. This model ran in production in 2017. Under the hood is a 3-cylinder diesel liquid-cooled engine, paired with four-wheel drive with a hydrostatic transmission. It has a listed operating weight of 275 kg, and it suits operations of up to 200 ac. Detailed specifications in both UK and US units follow below.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

23 hp

Max power

21.6 hp (3,200 rpm)

Weight

275 kg

Catalogue coverage

Variants represented

Richest spec table

91 rows

Recorded power

23 hp

Recorded weight

275 kg

Transmissions

hydrostatic

Production years

2017-2017

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Backhoe loader tractorReference

Original price was $20,325 in 2017Reference

Four-wheel driveReference

Power steeringReference

Wet disc brakesReference

Two-post foldable ROPS.Reference

Variants

BX2380utility tractorReference

BX23Sloader-backhoe tractorReference

Engine

Kubota 0.9L 3-cyl dieselReference

Fuel tank25.0 LReference

Engine (gross)17.2 kWReference

Engine (net)15.2 kWReference

Kubota D902Reference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement0.9 LReference

Bore/Stroke72 x 74 mmReference

EmissionsTier IVReference

Power (net)15.2 kWReference

Power (gross)17.2 kWReference

Rated RPM3200Reference

StarterelectricReference

Starter volts12Reference

Oil capacity3.3 LReference

Coolant capacity3.1 LReference

Fuel TypeDieselReference

Transmission

hydrostaticReference

TypehydrostaticReference

Gearsinfinite forward and reverse (2-range)Reference

Transmission TypeHSTReference

forward and reverse options2x2Reference

forward speed range13.5 kmphReference

reverse speed range10.5 kmphReference

Wheel Drive4WDReference

PTO & Hydraulics

Pump flow23.5 lpmReference

Dimensions

Wheelbase139 cmReference

Front tire18x8.5-10Reference

Rear tire26x12-12Reference

Weight275 kgReference

Industrial front18x8.5-10Reference

Industrial rear26x12-12Reference

Width121 cmReference

Height (ROPS)211 cmReference

Height (backhoe)171 cmReference

Clearance (front axle)21 cmReference

Front tread92 cmReference

Rear tread81 cmReference

Backhoe & Loader

Dig depth185 cmReference

Dump angle114 cmReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps40Reference

Battery CCA560Reference

Battery volts12Reference

Attachment overview

Kubota LA340 loaderReference

Kubota LA340S loaderReference

BackhoeReference

Kubota BT603 Backhoe

Backhoe typeKubota BT603 BackhoeReference

Transport height171 cmReference

Digging depth185 cmReference

Reach from pivot261 cmReference

Loading height152 cmReference

Bucket Rotation180°Reference

Swing Arc140°Reference

Bucket force878 kgReference

Dipperstick force531 kgReference

General

Make & ModelKubota D902Reference

Cruise controltrueReference

Capacities

Capacity898 ccReference

Power

Max Power21.6 hp (3,200 rpm)Reference

PTO

PTO Power17.7 hpReference

Rear PTO PowerYESReference

Rear PTO RPM540Reference

Mid PTOYESReference

Mid PTO RPM2,500Reference

Steering & brakes

BrakesWet discReference

Steering typeHydrostatic power steeringReference

Hydraulics

Pump Rated Output (total)23.5 l/minReference

Rear Hitch category (SAE designation)Category 1Reference

Dimensions & weight

Height Over ROPS2,190 mmReference

Overall Width1,145 mmReference

Front axle clearance213 mmReference

Turning radius2.3 mReference

Overall weight712.1 kgReference

Wheels & tyres

Rear Wheel Type26x12-12Reference

Rear wheel tread range820 mmReference

Front Wheel Type18x8.5-10Reference

Front Wheel tread range930 mmReference

Operator station

Cab AvailabilityOptionalReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
