Tractor · 2016Unverified
Kubota FT220
Kubota FT220 — FT Granforce Series · 22 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
22 hp
Weight
2006 to 2271 pounds
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Compact Utility tractorReference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS. Cab optional with air-conditioning.Reference
Variants
FT220wheeledReference
FT220-PChalf-trackReference
Engine
Kubota 1.5L 3-cyl dieselReference
Fuel tank28.0 LReference
Engine16.2 kWReference
Kubota D1503Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.5 LReference
Bore/Stroke83 x 92 mmReference
Power16.2 kWReference
Rated RPM2500Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speedReference
Gears12 forward and reverseReference
Clutchdry discReference
Three gears (1-3) in four ranges (creeper, low, medium, high) with shuttle shift.Reference
PTO & Hydraulics
Rear TypeIReference
Rear PTO Type540 (1.375)Reference
Engine RPM498@2500Reference
Engine RPM720@2500Reference
Engine RPM1061@2500Reference
Engine RPM-606Reference
Engine RPM2500Reference
Dimensions
Wheelbase150 cmReference
Weight2006 to 2271 poundsReference
Front tire6-14Reference
Rear tire8.3-24Reference
Standard tires (ag)Front: 6-14. Rear: 8.3-24Reference
Optional tires (ag)Front: 6-14. Rear: 9.5-22Reference
Length290 cmReference
ROPS Width117 cmReference
Cab Width131 cmReference
Height (ROPS)190 cmReference
Height (cab)194 cmReference
ROPS Weight909 kgReference
Cab Weight1030 kgReference
Ground clearance32 cmReference
Front tread97 cmReference
Rear tread94/106 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
