Kubota FT240
Kubota FT240 — FT Granforce Series · 24 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
24 hp
Weight
2017 to 2293 pounds
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Compact Utility tractorReference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS. Cab optional with air-conditioning.Reference
Variants
FT240wheeledReference
FT240-PChalf-trackReference
Engine
Kubota 1.5L 3-cyl dieselReference
Fuel tank28.0 LReference
Engine17.7 kWReference
Kubota D1503Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.5 LReference
Bore/Stroke83 x 92 mmReference
Power17.7 kWReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speedReference
Gears12 forward and reverseReference
Clutchdry discReference
Three gears (1-3) in four ranges (creeper, low, medium, high) with shuttle shift.Reference
PTO & Hydraulics
Rear TypeIReference
Rear PTO Type540 (1.375)Reference
Engine RPM490@2600Reference
Engine RPM709@2600Reference
Engine RPM1103@2600Reference
Engine RPM-597@2600Reference
Dimensions
Wheelbase150 cmReference
Weight2017 to 2293 poundsReference
Front tire4-14Reference
Rear tire9.5-22Reference
Standard tires (ag)Front: 4-14. Rear: 9.5-22Reference
Optional tires (ag)Front: 6-14. Rear: 9.5-24Reference
Length290 cmReference
ROPS Width118 cmReference
Cab Width131 cmReference
Height (ROPS)190 cmReference
Height (cab)194 cmReference
ROPS Weight914 kgReference
Cab Weight1040 kgReference
Ground clearance32 cmReference
Front tread97 cmReference
Rear tread94/106 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
