Tractor · 2016Unverified

Kubota FT240-PC Power Crawler

Name: Kubota FT240-PC Power Crawler
Brand: Kubota

Kubota FT240-PC Power Crawler — FT Granforce Series · 24 hp. Reference specifications; pending source verification.

The Kubota FT240-PC Power Crawler is a compact tractor with a rated output of 24 hp. It was manufactured in 2016 and features a 3-cylinder diesel liquid-cooled engine. This engine drives through a tracked undercarriage with a 12-speed gearbox, and the machine has a listed weight of 2579 to 2866 pounds. It is designed for use on areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

24 hp

Weight

2579 to 2866 pounds

Catalogue coverage

Variants represented

Richest spec table

48 rows

Recorded power

24 hp

Recorded weight

1169 kg

Transmissions

12-speed

Production years

2016-2016

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Half-track Crawler tractorReference

Drivehalf-trackReference

Power steeringReference

Wet disc brakesReference

Two-post folding ROPS. Cab optional with air-conditioning.Reference

Variants

FT240wheeledReference

FT240-PChalf-trackReference

Engine

Kubota 1.5L 3-cyl dieselReference

Fuel tank28.0 LReference

Engine17.7 kWReference

Kubota D1503Reference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.5 LReference

Bore/Stroke83 x 92 mmReference

Power17.7 kWReference

Rated RPM2600Reference

StarterelectricReference

Starter volts12Reference

Transmission

12-speedReference

Gears12 forward and reverseReference

Clutchdry discReference

Three gears (1-3) in four ranges (creeper, low, medium, high) with shuttle shift.Reference

PTO & Hydraulics

Rear TypeIReference

Rear PTO Type540 (1.375)Reference

Engine RPM490@2600Reference

Engine RPM709@2600Reference

Engine RPM1103@2600Reference

Engine RPM-597@2600Reference

Dimensions

Wheelbase150 cmReference

Weight2579 to 2866 poundsReference

Front tire7-16Reference

Rear tiretracksReference

Ag front7-16Reference

Ag rear330mm trackReference

Length290 cmReference

Width137 cmReference

Height (ROPS)197 cmReference

Height (cab)201 cmReference

ROPS Weight1169 kgReference

Cab Weight1300 kgReference

Ground clearance38 cmReference

Front tread104 cmReference

Rear tread103 cmReference

Electrical

GroundnegativeReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
