Tractor · 2012Unverified

Kubota FT25-PC Power Crawler

Name: Kubota FT25-PC Power Crawler
Brand: Kubota

Kubota FT25-PC Power Crawler — FT Granforce Series · 25 hp. Reference specifications; pending source verification.

The Kubota FT25-PC Power Crawler is a tractor rated at approximately 25 hp, which positions it at the lower end of its class. It was produced from 2012 to 2015. The FT25-PC Power Crawler features a 3-cylinder diesel liquid-cooled engine, paired with a tracked undercarriage and a powershift transmission. Its listed operating weight ranges from 2568 to 2899 pounds, with a recommended operating capacity of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

25 hp

Weight

2568 to 2899 pounds

Catalogue coverage

Variants represented

Richest spec table

55 rows

Recorded power

25 hp

Transmissions

12-speed

Production years

2012-2015

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Half-track Crawler tractorReference

Drivehalf-trackReference

Power steeringReference

Wet disc brakesReference

Two-post folding ROPS. Cab optional with air-conditioning.Reference

Variants

FT25wheeledReference

FT25-PChalf-trackReference

Engine

Kubota 1.5L 3-cyl dieselReference

Fuel tank29.9 LReference

Engine18.4 kWReference

Kubota D1503Reference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.5 LReference

Bore/Stroke83 x 92 mmReference

Power18.4 kWReference

Rated RPM2600Reference

StarterelectricReference

Starter volts12Reference

Transmission

12-speedReference

48-speed power shiftReference

ROPS gear1164 kgReference

Cab gear1295 kgReference

Gears12 forward and reverseReference

Clutchdry discReference

Three gears (1-3) in four ranges (creeper, low, medium, high) with shuttle shift.Reference

TransmissionGlideshiftReference

Typepower shiftReference

Gears48 forward and 30 reverseReference

Sixteen gears (10 in reverse) with three ranges. Gears may be shifted sequentially while moving, without using the clutch. Tractor must be stopped, and clutch used, to shift ranges.Reference

PTO & Hydraulics

Rear TypeIReference

Rear PTO Type540 (1.375)Reference

Engine RPM525@2600Reference

Engine RPM760@2600Reference

Engine RPM1182@2600Reference

Engine RPM-640@2600Reference

Dimensions

Wheelbase150 cmReference

Weight2568 to 2899 poundsReference

Front tire7-16Reference

Rear tiretracksReference

Ag front7-16Reference

Ag rear330mm trackReference

Length290 cmReference

Width137 cmReference

Height (ROPS)197 cmReference

Height (cab)201 cmReference

Ground clearance38 cmReference

Front tread104 cmReference

Rear tread103 cmReference

ROPS Glideshift1184 kgReference

Cab Glideshift1314 kgReference

Electrical

GroundnegativeReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
