Tractor · 2012Unverified

Kubota FT30

Name: Kubota FT30
Brand: Kubota

Kubota FT30 — FT Granforce Series · 30 hp. Reference specifications; pending source verification.

The Kubota FT30 is a tractor with a rated output of approximately 30 horsepower, positioning it at the lower end of its class in terms of engine power. Produced between 2012 and 2015, this model is equipped with a 3-cylinder diesel liquid-cooled engine and features four-wheel drive with a powershift transmission. The tractor's operating weight is specified as between 2161 and 2469 pounds. It is suitable for use in operations of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

30 hp

Max power

29.6 hp

Weight

2161 to 2469 pounds

Catalogue coverage

Variants represented

Richest spec table

80 rows

Recorded power

30 hp

Transmissions

12-speed

Production years

2012-2015

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Compact Utility tractorReference

Four-wheel driveReference

Power steeringReference

Wet disc brakesReference

Two-post folding ROPS. Cab optional with air-conditioning.Reference

Engine

Kubota 1.6L 3-cyl dieselReference

Fuel tank29.9 LReference

Engine22.1 kWReference

Kubota D1703Reference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.6 LReference

Bore/Stroke86 x 91 mmReference

Power22.1 kWReference

Rated RPM2700Reference

StarterelectricReference

Starter volts12Reference

Fuel TypedieselReference

No of Cylinders3 CylinderReference

Rated engine speed2,700 RPMReference

Bore and stroke3.4x3.6 inchesReference

Cooling systemliquid-cooledReference

Transmission

12-speedReference

48-speed power shiftReference

ROPS gear980 kgReference

Cab gear1099 kgReference

Gears12 forward and reverseReference

Clutchdry discReference

Three gears (1-3) in four ranges (creeper, low, medium, high) with shuttle shift.Reference

TransmissionGlideshiftReference

Typepower shiftReference

Gears48 forward and 30 reverseReference

Sixteen gears (10 in reverse) with three ranges. Gears may be shifted sequentially while moving, without using the clutch. Tractor must be stopped, and clutch used, to shift ranges.Reference

Transmission TypePowershiftReference

forward and reverse options12F and 12R |Glideshift : Powershift- 48F and 30RReference

Wheel Drive4WDReference

PTO & Hydraulics

Rear TypeIReference

Rear PTO Type540 (1.375)Reference

Engine RPM545@2700Reference

Engine RPM789@2700Reference

Engine RPM1227@2700Reference

Engine RPM-664@2700Reference

Dimensions

Wheelbase150 cmReference

Weight2161 to 2469 poundsReference

Front tire7-16Reference

Rear tire11.2-26Reference

Standard tires (ag)Front: 7-16. Rear: 11.2-26Reference

Length292 cmReference

Width132 cmReference

Height (ROPS)196 cmReference

Height (cab)201 cmReference

Ground clearance37 cmReference

Front tread105 cmReference

Rear tread104 cmReference

ROPS Glideshift1000 kgReference

Cab Glideshift1119 kgReference

Electrical

GroundnegativeReference

Battery volts12Reference

General

Make & ModelKubotaReference

Rollover protective structureTwo-post folding ROPSReference

Capacities

Capacity100.5 ciReference

Power

Max Power29.6 hpReference

PTO

Rear PTO PowerAvailableReference

Rear PTO RPM540 RPMReference

Engine Speed on Rear PTO speed545@2,700Reference

Steering & brakes

Brakeswet discReference

Steering typepowerReference

Hydraulics

Rear Hitch category (SAE designation)Category IReference

Dimensions & weight

Height Over ROPS196.1 cmReference

Height Over Cab201.4 cmReference

Overall Length292.1 cmReference

Overall Width132.6 cmReference

Overall weight1,000.2 kgReference

Wheels & tyres

Rear Wheel Type11.2-26 agReference

Rear wheel tread range104.9 cmReference

Front Wheel Type7-16 agReference

Front Wheel tread range105.4 cmReference

Operator station

Cab AvailabilityAvailableReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
