Tractor · 2016Unverified

Kubota FT300-PC Power Crawler

Name: Kubota FT300-PC Power Crawler
Brand: Kubota

Kubota FT300-PC Power Crawler — FT Granforce Series · 30 hp. Reference specifications; pending source verification.

The Kubota FT300-PC Power Crawler is a compact tractor model with a rated output of 30 hp. It was produced in 2016 and features a 3-cylinder diesel liquid-cooled engine, paired with a tracked undercarriage and powershift transmission. The listed weight range for the FT300-PC Power Crawler is 2756 to 3031 pounds, and it is designed for use in areas of approximately 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

30 hp

Weight

2756 to 3031 pounds

Catalogue coverage

Variants represented

Richest spec table

48 rows

Recorded power

30 hp

Recorded weight

1250 kg

Transmissions

48-speed power shift

Production years

2016-2016

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Half-track Crawler tractorReference

Drivehalf-trackReference

Power steeringReference

Wet disc brakesReference

Two-post folding ROPS. Cab optional with air-conditioning.Reference

Variants

FT300wheeledReference

FT300-PChalf-trackReference

Engine

Kubota 1.8L 3-cyl dieselReference

Fuel tank26.9 LReference

Engine22.1 kWReference

Kubota D1803Reference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.8 LReference

Bore/Stroke86 x 102 mmReference

Power22.1 kWReference

Rated RPM2700Reference

StarterelectricReference

Starter volts12Reference

Transmission

48-speed power shiftReference

TransmissionGlideshiftReference

Typepower shiftReference

Gears48 forward and 30 reverseReference

PTO & Hydraulics

Rear TypeIReference

Rear PTO Type540 (1.375)Reference

Engine RPM509@2700Reference

Engine RPM736@2700Reference

Engine RPM1145@2700Reference

Engine RPM-620@2700Reference

Dimensions

Wheelbase150 cmReference

Weight2756 to 3031 poundsReference

Front tire7-16Reference

Rear tiretracksReference

Ag front7-16Reference

Ag rear330mm trackReference

Length297 cmReference

Width137 cmReference

Height (ROPS)197 cmReference

Height (cab)202 cmReference

ROPS Weight1250 kgReference

Cab Weight1374 kgReference

Ground clearance38 cmReference

Front tread104 cmReference

Rear tread103 cmReference

Electrical

GroundnegativeReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
