Tractor · 2016Unverified
Kubota FT300-PC Power Crawler
Kubota FT300-PC Power Crawler — FT Granforce Series · 30 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
30 hp
Weight
2756 to 3031 pounds
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Half-track Crawler tractorReference
Drivehalf-trackReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS. Cab optional with air-conditioning.Reference
Variants
FT300wheeledReference
FT300-PChalf-trackReference
Engine
Kubota 1.8L 3-cyl dieselReference
Fuel tank26.9 LReference
Engine22.1 kWReference
Kubota D1803Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.8 LReference
Bore/Stroke86 x 102 mmReference
Power22.1 kWReference
Rated RPM2700Reference
StarterelectricReference
Starter volts12Reference
Transmission
48-speed power shiftReference
TransmissionGlideshiftReference
Typepower shiftReference
Gears48 forward and 30 reverseReference
PTO & Hydraulics
Rear TypeIReference
Rear PTO Type540 (1.375)Reference
Engine RPM509@2700Reference
Engine RPM736@2700Reference
Engine RPM1145@2700Reference
Engine RPM-620@2700Reference
Dimensions
Wheelbase150 cmReference
Weight2756 to 3031 poundsReference
Front tire7-16Reference
Rear tiretracksReference
Ag front7-16Reference
Ag rear330mm trackReference
Length297 cmReference
Width137 cmReference
Height (ROPS)197 cmReference
Height (cab)202 cmReference
ROPS Weight1250 kgReference
Cab Weight1374 kgReference
Ground clearance38 cmReference
Front tread104 cmReference
Rear tread103 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
