Lawn Tractor · 1983Unverified
Kubota G3200
Kubota G3200 — G Series · 10 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
10 hp
Weight
310 kg
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Garden tractorReference
Two-wheel driveReference
Disc brakesReference
Open operator station.Reference
Engine
10HP Kubota 399cc 2-cyl dieselReference
Fuel tank7.9 LReference
Kubota Z400Reference
dieselReference
2-cylinderReference
liquid-cooled horizonal-shaftReference
Displacement24.4 ciReference
Bore/Stroke64 x 62 mmReference
Power (gross)7.5 kWReference
Pre-heatingglow plugsReference
Rated RPM3200Reference
StarterelectricReference
Starter volts12Reference
Starter power0.7 kWReference
Coolant capacity1.9 LReference
Image courtesy of J. McCrackenReference
Transmission
3-speed gearReference
TypegearReference
Gears3 forward and 1 reverseReference
Clutchdouble dry discReference
Oil capacity8.0 LReference
PTO & Hydraulics
Rear Type0Reference
Rear PTOindependentReference
Rear PTO Type2000Reference
Front PTOindependentReference
Clutchmanual idler pulleyReference
Front PTO Type1-inchReference
Dimensions
Wheelbase119 cmReference
Weight310 kgReference
Front tire16x6.50-8Reference
Rear tire23x10.50-12Reference
Lawn/turf front16x6.50-8Reference
Lawn/turf rear23x10.50-12Reference
Length180 cmReference
Min Width96 cmReference
Max Width102 cmReference
Height112 cmReference
Ground clearance17 cmReference
Front tread73 cmReference
Rear tread69/75 cmReference
310 kgReference
Max front axle299 kgReference
Max rear axle548 kgReference
Kubota G3200 attachments
40" mid-mount mower deckReference
44" mid-mount mower deckReference
snowblowerReference
bladeReference
G3200 Serial Numbers
Location:Serial number decal on the left side of G3200 tractor frame, above front axle.Reference
Electrical
GroundnegativeReference
Battery volts12Reference
Battery AH35Reference
Attachment overview
40" mid-mount mower deckReference
44" mid-mount mower deckReference
SnowblowerReference
BladeReference
Capacities
Max capacity698 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
