Tractor · 1997Unverified
Kubota GB20
Kubota GB20 — GB Series · 20 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
20 hp
Weight
1543 to 1587 pounds
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Sub-Compact Utility tractorReference
Four-wheel driveReference
Power steeringReference
Mechanical wet disc brakesReference
Two-post ROPS.Reference
Variants
GB20FGlideshiftReference
Engine
Kubota 1.1L 3-cyl dieselReference
Fuel tank20.1 LReference
Engine14.7 kWReference
Kubota D1105Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.1 LReference
Bore/Stroke78 x 78 mmReference
Power14.7 kWReference
Rated RPM2600Reference
StarternegativeReference
Starter volts12Reference
Transmission
6-speed gearReference
18-speedReference
Gear Weight699 kgReference
TypegearReference
Gears6 forward and 2 reverseReference
Three gears, plus reverse, in two ranges.Reference
TransmissionGlideshiftReference
Gears18 forward and 9 reverseReference
Six forward and three reverse gears in three ranges.Reference
PTO & Hydraulics
Rear Type0Reference
Controlposition controlReference
Rear PTO Type451/769/1207 (1.375)Reference
Dimensions
Wheelbase135 cmReference
Weight1543 to 1587 poundsReference
Front tire6.00-12Reference
Rear tire8.3-22Reference
Standard tires (ag)Front: 6.00-12. Rear: 8.3-22Reference
Length234 cmReference
Width104 cmReference
Height (ROPS)187 cmReference
Glideshift Weight719 kgReference
Ground clearance33 cmReference
Front tread84 cmReference
Rear tread81/89 cmReference
GB20 Serial Number Location
Serial number tag on the right side of the tractor frame, above the front axle.Reference
Electrical
GroundelectricReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
