Tractor · 2002Unverified

Kubota GB200

Name: Kubota GB200
Brand: Kubota

Kubota GB200 — GB Series · 20 hp. Reference specifications; pending source verification.

The Kubota GB200 is a compact tractor with a rating of 20 hp, making it a suitable option for smaller-scale operations. It was produced between 2002 and 2003, and is equipped with a 3-cylinder diesel liquid-cooled engine, which powers a four-wheel drive system via a 9-speed gearbox. The tractor's weight falls within the range of 1554 to 1609 pounds. It is designed for use on areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

20 hp

Weight

1554 to 1609 pounds

Catalogue coverage

Variants represented

Richest spec table

46 rows

Recorded power

20 hp

Recorded weight

704 kg

Transmissions

9-speed gear

Production years

2002-2003

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Sub-Compact Utility tractorReference

Four-wheel driveReference

Power steeringReference

Mechanical wet disc brakesReference

Two-post ROPS.Reference

Variants

GB200FGlideshiftReference

Engine

Kubota 1.1L 3-cyl dieselReference

Fuel tank20.1 LReference

Engine14.7 kWReference

Kubota D1105Reference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.1 LReference

Bore/Stroke78 x 78 mmReference

Power14.7 kWReference

Rated RPM2600Reference

StarternegativeReference

Starter volts12Reference

Transmission

9-speed gearReference

18-speedReference

Gear Weight704 kgReference

TypegearReference

Gears9 forward and 3 reverseReference

Three gears, plus reverse, in three ranges.Reference

TransmissionGlideshiftReference

Gears18 forward and 9 reverseReference

Six forward and three reverse gears in three ranges.Reference

PTO & Hydraulics

Rear Type0Reference

Controlposition controlReference

Rear PTO Type451/769/1207 (1.375)Reference

Dimensions

Wheelbase135 cmReference

Weight1554 to 1609 poundsReference

Front tire6.00-12Reference

Rear tire9.5-20Reference

Standard tires (ag)Front: 6.00-12. Rear: 9.5-20Reference

Length234 cmReference

Width110 cmReference

Height (ROPS)187 cmReference

Glideshift Weight729 kgReference

Ground clearance33 cmReference

Front tread84 cmReference

Rear tread84/87 cmReference

Electrical

GroundelectricReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
