Tractor · 1991Unverified

Kubota GL-35

Name: Kubota GL-35
Brand: Kubota

Kubota GL-35 — GL Series · 35 hp. Reference specifications; pending source verification.

The Kubota GL-35 is a tractor with a rated power output of 35 hp, positioning it at the lower end of its class in terms of power output. It was manufactured from 1991 to 1995. The tractor is equipped with a 3-cylinder diesel liquid-cooled engine, paired with four-wheel drive and a 16-speed gearbox. Its operating weight is listed as 3472 to 3825 pounds.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

35 hp

Weight

3472 to 3825 pounds

Catalogue coverage

Variants represented

Richest spec table

43 rows

Recorded power

35 hp

Recorded weight

1574 kg

Transmissions

16-speed

Production years

1991-1995

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Compact Utility tractorReference

Four-wheel driveReference

Power steeringReference

Two-post ROPS. Cab optional.Reference

Engine

Kubota 1.5L 3-cyl dieselReference

Fuel tank50.0 LReference

Engine26.1 kWReference

Kubota D1503-TReference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.5 LReference

Bore/Stroke83 x 92 mmReference

Power26.1 kWReference

Rated RPM2700Reference

StarterelectricReference

Starter volts12Reference

Transmission

16-speedReference

Gears16 forward and reverseReference

PTO & Hydraulics

Rear TypeJIS1Reference

Rear PTO Type540 (1.375)Reference

Engine RPM578@2700Reference

Engine RPM781@2700Reference

Engine RPM950@2700Reference

Engine RPM1249@2700Reference

Engine RPM-781@2700Reference

Dimensions

Wheelbase184 cmReference

Weight3472 to 3825 poundsReference

Front tire8-18Reference

Rear tire12.4-28Reference

Standard tires (ag)Front: 8-18. Rear: 12.4-28Reference

Length349 cmReference

Width146 cmReference

Height (ROPS)198 cmReference

Height (cab)199 cmReference

ROPS Weight1574 kgReference

Cab Weight1735 kgReference

Ground clearance36 cmReference

Front tread120 cmReference

Rear tread114 to 160 cmReference

Electrical

GroundnegativeReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
