Tractor · 1991Unverified

Kubota GL-46

Name: Kubota GL-46
Brand: Kubota

Kubota GL-46 — GL Series · 46 hp. Reference specifications; pending source verification.

The Kubota GL-46 is a tractor model with a rated output of 46 hp, classifying it as one of the more compact options in its class. It was manufactured between 1991 and 1995. The tractor is powered by a 5-cylinder diesel liquid-cooled engine, which drives through four-wheel drive via a 16-speed gearbox. Its listed weight ranges from 3748 to 4167 pounds.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

46 hp

Weight

3748 to 4167 pounds

Catalogue coverage

Variants represented

Richest spec table

42 rows

Recorded power

46 hp

Recorded weight

1700 kg

Transmissions

16-speed

Production years

1991-1995

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Compact Utility tractorReference

Four-wheel driveReference

Power steeringReference

Two-post ROPS. Cab optional.Reference

Engine

Kubota 2.5L 5-cyl dieselReference

Fuel tank50.0 LReference

Engine34.3 kWReference

Kubota F2503Reference

dieselReference

5-cylinderReference

liquid-cooledReference

Displacement2.5 LReference

Bore/Stroke84 x 91 mmReference

Power34.3 kWReference

Rated RPM2600Reference

StarterelectricReference

Starter volts12Reference

Transmission

16-speedReference

Gears16 forward and reverseReference

PTO & Hydraulics

Rear TypeJIS1Reference

Rear PTO Type540 (1.375)Reference

Engine RPM585@2600Reference

Engine RPM789@2600Reference

Engine RPM961@2600Reference

Engine RPM1263@2600Reference

Dimensions

Wheelbase198 cmReference

Weight3748 to 4167 poundsReference

Front tire8-18Reference

Rear tire13.6-28Reference

Standard tires (ag)Front: 8-18. Rear: 13.6-28Reference

Length362 cmReference

Width155 cmReference

Height (ROPS)219 cmReference

Height (cab)235 cmReference

ROPS Weight1700 kgReference

Cab Weight1890 kgReference

Ground clearance36 cmReference

Front tread120 cmReference

Rear tread115 to 161 cmReference

Electrical

GroundnegativeReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
