Tractor · 1993Unverified

Kubota GL260

Name: Kubota GL260
Brand: Kubota

Kubota GL260 — GL Series · 24 hp. Reference specifications; pending source verification.

The Kubota GL260 is a compact tractor with a rating of 24 hp. It was manufactured from 1993 to 1995 and is equipped with a 3-cylinder diesel liquid-cooled engine. The tractor features four-wheel drive and a powershift transmission. Its listed weight is 2601 to 2888 pounds, and it is suitable for use on areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

24 hp

Weight

2601 to 2888 pounds

Catalogue coverage

Variants represented

Richest spec table

50 rows

Recorded power

24 hp

Recorded weight

1179 kg

Transmissions

16-speed gear

Production years

1993-1995

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Compact Utility tractorReference

Four-wheel driveReference

Power steeringReference

Mechanical wet disc brakesReference

Two-post ROPS. Cab optional.Reference

Variants

GL260ROPSReference

GL260QcabReference

GL280Jlarge wheelReference

Engine

Kubota 1.5L 3-cyl dieselReference

Fuel tank26.9 LReference

Engine19.1 kWReference

Kubota D1503Reference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.5 LReference

Bore/Stroke83 x 92 mmReference

Power19.1 kWReference

Rated RPM2600Reference

StarterelectricReference

Starter volts12Reference

Transmission

16-speed gearReference

16-speed power shiftReference

TypegearReference

Gears16 forward and reverseReference

Clutchdry discReference

Four gears (1-4) in two ranges (low/high) with additional creeper range and shuttle shift.Reference

Typepower shiftReference

PTO & Hydraulics

PTO (claimed)17.9 kWReference

Pump flow21.2 lpmReference

Rear TypeIReference

Rear lift934 kgReference

Rear PTO Type568/803/985/1304 (1.375)Reference

Dimensions

Wheelbase164 cmReference

Weight2601 to 2888 poundsReference

Front tire7-16Reference

Rear tire11.2-24Reference

Standard tires (ag)Front: 7-16. Rear: 11.2-24Reference

Length305 cmReference

Width135 cmReference

Height (ROPS)195 cmReference

Height (cab)199 cmReference

ROPS Weight1179 kgReference

Cab Weight1309 kgReference

Ground clearance34 cmReference

Front tread107 cmReference

Rear tread104 to 134 cmReference

Electrical

GroundnegativeReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
