Tractor · 1996Unverified
Kubota GL281
Kubota GL281 — GL Series · 28 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
28 hp
Weight
2679 to 3086 pounds
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Compact Utility tractorReference
Four-wheel driveReference
Power steeringReference
Mechanical wet disc brakesReference
Two-post ROPS. Cab optional.Reference
Engine
Kubota 1.5L 3-cyl dieselReference
Fuel tank26.9 LReference
Engine21.3 kWReference
Kubota D1503Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.5 LReference
Bore/Stroke83 x 92 mmReference
Power21.3 kWReference
Rated RPM2700Reference
StarterelectricReference
Starter volts12Reference
Transmission
16-speed gearReference
16-speed power shiftReference
TypegearReference
Gears16 forward and reverseReference
Clutchdry discReference
Four gears (1-4) in two ranges (low/high) with additional creeper range and shuttle shift.Reference
TransmissionU-ShiftReference
Typepower shiftReference
Eight power-shift gears in two ranges with shuttle.Reference
PTO & Hydraulics
PTO (claimed)20.6 kWReference
Pump flow22.3 lpmReference
Rear TypeJIS1Reference
Rear lift870 kgReference
Rear PTO Type540 (1.375)Reference
Engine RPM545@2700Reference
Engine RPM771@2700Reference
Engine RPM945@2700Reference
Engine RPM1252@2700Reference
Engine RPM-771@2700Reference
Dimensions
ROPS Wheelbase164 cmReference
Cab Wheelbase169 cmReference
Weight2679 to 3086 poundsReference
Front tire8-16Reference
Rear tire11.2-26Reference
Standard tires (ag)Front: 8-16. Rear: 11.2-26Reference
ROPS Length305 cmReference
Cab Length312 cmReference
Width139 cmReference
Height (ROPS)199 cmReference
Height (cab)198 cmReference
ROPS Weight1215 kgReference
Cab Weight1399 kgReference
Ground clearance36 cmReference
Front tread113 cmReference
Rear tread113 to 141 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
