The Kubota GL301E is a compact tractor model with a rated output of 29 hp, distinguishing it within its class. It was manufactured from 1996 to 2001. The tractor features a 3-cylinder diesel liquid-cooled engine, coupled with a 16-speed gearbox and four-wheel drive. The listed weight is 1179 kg, suitable for tasks covering areas of up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
29 hp
Weight
1179 kg
Catalogue coverage
Variants represented
2
Richest spec table
44 rows
Recorded power
29 hp
Recorded weight
1179 kg
Transmissions
16-speed gear
Production years
1996-2001
Verified variants
0
1 linked source document displayed
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Orchard/Vineyard tractorReference
Four-wheel driveReference
Power steeringReference
Mechanical wet disc brakesReference
Two-post ROPS.Reference
Variants
GL301utilityReference
GL301EnarrowReference
Engine
Kubota 1.5L 3-cyl dieselReference
Fuel tank35.0 LReference
Engine22.8 kWReference
Kubota D1503Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.5 LReference
Bore/Stroke83 x 92 mmReference
Power22.8 kWReference
Rated RPM2700Reference
StarterelectricReference
Starter volts12Reference
Transmission
16-speed gearReference
TypegearReference
Gears16 forward and reverseReference
Clutchdry discReference
Four gears (1-4) in two ranges (low/high) with additional creeper range and shuttle shift.Reference
PTO & Hydraulics
PTO (claimed)21.7 kWReference
Pump flow22.3 lpmReference
Rear TypeIReference
Rear lift904 kgReference
Rear PTO Type565/800/980/1298 (1.375)Reference
Dimensions
Wheelbase164 cmReference
Weight1179 kgReference
Front tire7-16Reference
Rear tire11.2-24Reference
Standard tires (ag)Front: 7-16. Rear: 11.2-24Reference
Length305 cmReference
Width132 cmReference
Height (ROPS)195 cmReference
Ground clearance34 cmReference
Front tread107 cmReference
Rear tread104 to 134 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
