Tractor · 1996Unverified
Kubota GL337
Kubota GL337 — GL Series · 28 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
28 hp
Weight
2822 to 3230 pounds
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Compact Utility tractorReference
Four-wheel driveReference
Power steeringReference
Mechanical wet disc brakesReference
Two-post ROPS. Cab optional.Reference
Engine
Kubota 1.6L 3-cyl dieselReference
Fuel tank35.0 LReference
Engine24.3 kWReference
Kubota D1703Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.6 LReference
Bore/Stroke86 x 91 mmReference
Power24.3 kWReference
Rated RPM2700Reference
StarterelectricReference
Starter volts12Reference
Transmission
16-speed power shiftReference
Typepower shiftReference
Gears16 forward and reverseReference
PTO & Hydraulics
PTO (claimed)20.8 kWReference
Pump flow22.3 lpmReference
Rear TypeJIS1Reference
Rear lift904 kgReference
Rear PTO Type540 (1.375)Reference
Engine RPM565@2700Reference
Engine RPM800@2700Reference
Engine RPM980@2700Reference
Engine RPM1298@2700Reference
Engine RPM-800@2700Reference
Dimensions
Wheelbase175 cmReference
Weight2822 to 3230 poundsReference
Front tire8-16Reference
Rear tire13.6-24Reference
Standard tires (ag)Front: 8-16. Rear: 13.6-24Reference
Length318 cmReference
Width145 cmReference
Height (ROPS)198 cmReference
Height (cab)211 cmReference
ROPS Weight1280 kgReference
Cab Weight1465 kgReference
Ground clearance36 cmReference
Front tread113 cmReference
Rear tread110 to 157 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
