Tractor · 1993Unverified

Kubota GL368

Name: Kubota GL368
Brand: Kubota

Kubota GL368 — GL Series · 32 hp. Reference specifications; pending source verification.

The Kubota GL368 is a compact tractor model rated at 32 hp. It was manufactured from 1993 to 1995 and features a 4-cylinder diesel liquid-cooled engine, driving through a four-wheel drive system with a powershift transmission. The listed weight of the Kubota GL368 is 3197 to 3616 pounds. It is designed for use on areas of approximately 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

32 hp

Weight

3197 to 3616 pounds

Catalogue coverage

Variants represented

Richest spec table

49 rows

Recorded power

32 hp

Recorded weight

1450 kg

Transmissions

16-speed gear

Production years

1993-1995

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Compact Utility tractorReference

Four-wheel driveReference

Power steeringReference

Mechanical wet disc brakesReference

Two-post ROPS. Cab optional.Reference

Variants

GL368ROPSReference

GL368QcabReference

Engine

Kubota 1.9L 4-cyl dieselReference

Fuel tank35.0 LReference

Engine26.5 kWReference

Kubota V1903Reference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement1.9 LReference

Bore/Stroke79 x 91 mmReference

Power26.5 kWReference

Rated RPM2600Reference

StarterelectricReference

Starter volts12Reference

Transmission

16-speed gearReference

16-speed power shiftReference

TypegearReference

Gears16 forward and reverseReference

Clutchdry discReference

Four gears (1-4) in two ranges (low/high) with additional creeper range and shuttle shift.Reference

Typepower shiftReference

PTO & Hydraulics

PTO (claimed)23.6 kWReference

Pump flow23.8 lpmReference

Rear TypeIReference

Rear lift865 kgReference

Rear PTO Type544/806/1252 (1.375)Reference

Dimensions

Wheelbase183 cmReference

Weight3197 to 3616 poundsReference

Front tire8-16Reference

Rear tire12.4-28Reference

Standard tires (ag)Front: 8-16. Rear: 12.4-28Reference

Length332 cmReference

Width150 cmReference

Height (ROPS)217 cmReference

Height (cab)229 cmReference

ROPS Weight1450 kgReference

Cab Weight1640 kgReference

Ground clearance36 cmReference

Front tread113 cmReference

Rear tread118 to 147 cmReference

Electrical

GroundnegativeReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
