Tractor · 1996Unverified

Kubota GL417

Name: Kubota GL417
Brand: Kubota

Kubota GL417 — GL Series · 38 hp. Reference specifications; pending source verification.

The Kubota GL417 is a compact tractor with a rated output of 38 hp. It was manufactured from 1996 to 2001 and features a 4-cylinder diesel liquid-cooled engine. This model is equipped with a powershift transmission and four-wheel drive, and its listed weight is 3175 to 3616 pounds. The GL417 is suitable for a range of tasks on approximately 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

38 hp

Weight

3175 to 3616 pounds

Catalogue coverage

Variants represented

Richest spec table

51 rows

Recorded power

38 hp

Recorded weight

1440 kg

Transmissions

16-speed gear

Production years

1996-2001

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Compact Utility tractorReference

Four-wheel driveReference

Power steeringReference

Mechanical wet disc brakesReference

Two-post ROPS. Cab optional.Reference

Engine

Kubota 2.2L 4-cyl dieselReference

Fuel tank35.0 LReference

Engine30.9 kWReference

Kubota V2203Reference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement2.2 LReference

Bore/Stroke87 x 92 mmReference

Power30.9 kWReference

Rated RPM2600Reference

StarterelectricReference

Starter volts12Reference

Transmission

16-speed gearReference

16-speed power shiftReference

TypegearReference

Gears16 forward and reverseReference

Clutchdry discReference

Four gears (1-4) in two ranges (low/high) with additional creeper range and shuttle shift.Reference

Typepower shiftReference

PTO & Hydraulics

PTO (claimed)28.2 kWReference

Pump flow23.8 lpmReference

Rear TypeJIS1Reference

Rear lift865 kgReference

Rear PTO Type540 (1.375)Reference

Engine RPM544@2600Reference

Engine RPM806@2600Reference

Engine RPM1252@2600Reference

Engine RPM-544@2600Reference

Dimensions

Wheelbase183 cmReference

Weight3175 to 3616 poundsReference

Front tire8-16Reference

Rear tire13.6-26Reference

Standard tires (ag)Front: 8-16. Rear: 13.6-26Reference

Length332 cmReference

Width149 cmReference

Height (ROPS)217 cmReference

Height (cab)215 cmReference

ROPS Weight1440 kgReference

Cab Weight1640 kgReference

Ground clearance36 cmReference

Front tread113 cmReference

Rear tread115 to 144 cmReference

Electrical

GroundnegativeReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
