Tractor · 1998Unverified
Kubota GM73
Kubota GM73 — GM Series · 68 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
68 hp
Weight
4982 to 5390 pounds
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Utility tractorReference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Two-post ROPS. Cab optional.Reference
Engine
Kubota 3.3L 4-cyl dieselReference
Fuel tank82.1 LReference
Engine53.6 kWReference
Kubota V3300Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.3 LReference
Bore/Stroke98 x 110 mmReference
Power53.6 kWReference
Rated RPM2500Reference
StarternegativeReference
Starter volts12Reference
Transmission
24-speedReference
Gears24 forward and reverseReference
Eight gears in three ranges with shuttle.Reference
PTO & Hydraulics
PTO (claimed)51.0 kWReference
Pump flow41.6 lpmReference
Rear TypeIReference
Controlposition and draft controlReference
Rear lift1730 kgReference
Rear lift2269 kgReference
Rear PTO Type564/795/1125 (1.375)Reference
Dimensions
Wheelbase215 cmReference
Weight4982 to 5390 poundsReference
Front tire9.5-24Reference
Rear tire16.9-30Reference
Standard tires (ag)Front: 9.5-24. Rear: 16.9-30Reference
Length365 cmReference
Width177 cmReference
Height (ROPS)251 cmReference
Height (cab)246 cmReference
ROPS Weight2259 kgReference
Cab Weight2444 kgReference
Ground clearance45 cmReference
Front tread119 to 150 cmReference
Rear tread132 to 171 cmReference
Electrical
GroundelectricReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
