Lawn Tractor · 2010Unverified
Kubota GR2020
Kubota GR2020 — GR Series · 20 hp. Reference specifications; pending source verification.
The Kubota GR2020 is a lawn tractor model with a rated power of 20 hp, making it one of the more powerful models in its class. It was manufactured from 2010 to 2014. It features a 2-cylinder petrol air-cooled engine and four-wheel drive with a hydrostatic transmission. The machine has an operating weight of 395 kg and is designed for use on areas of up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
20 hp
Weight
395 kg
Catalogue coverage
Variants represented
2
Richest spec table
46 rows
Recorded power
20 hp
Recorded weight
395 kg
Transmissions
hydrostatic
Production years
2010-2014
Verified variants
0
1 linked source document displayed
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Garden tractorReference
Original price was $8,362 in 2012Reference
Four-wheel driveReference
Steeringhydrostatic power (Glide Steer)Reference
Internal expanding brakesReference
Open operator station.Reference
Engine
20.0HP Kohler 624cc 2-cyl gasolineReference
Fuel tank15.9 LReference
Kohler GH630Reference
gasolineReference
2-cylinderReference
air-cooled horizontal-shaft V-TwinReference
Displacement38.1 ciReference
Bore/Stroke77 x 67 mmReference
Power (gross)14.9 kWReference
StarterelectricReference
Starter volts12Reference
Transmission
hydrostaticReference
Typeshaft-driven hydrostaticReference
Gearsinfinite forward and reverseReference
Hydrostatic transmission with single foot pedal and standard cruise control.Reference
Dimensions
Wheelbase128 cmReference
Weight395 kgReference
Front tire16x7.5-8Reference
Rear tire23x10.50-12Reference
Lawn/turf front16x7.5-8Reference
Lawn/turf rear23x10.50-12Reference
Length196 cmReference
Height129 cmReference
Weight395 kgReference
Front tread82 cmReference
Rear tread80 cmReference
Kubota GR2020 attachments
48" mid-mount mower deckReference
snowblowerReference
bladeReference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
48" mid-mount mower deckReference
SnowblowerReference
BladeReference
48" Mower deck
Typemid-mount KubotaReference
Type3-blade with hydraulic liftReference
Cutting width121 cmReference
Overall width154 cmReference
Cut height2 to 10 cmReference
