Tractor · 2001Unverified

Kubota GT-23

Name: Kubota GT-23
Brand: Kubota

Kubota GT-23 — GT Series · 23 hp. Reference specifications; pending source verification.

The Kubota GT-23 is a tractor model with a rating of approximately 23 horsepower, positioning it at the lighter end of its class. It was produced between 2001 and 2002. The GT-23 is powered by a 3-cylinder diesel liquid-cooled engine, coupled with four-wheel drive and a hydrostatic transmission. Its operating weight is listed as 1984 to 2072 pounds, and it is suitable for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

23 hp

Weight

1984 to 2072 pounds

Catalogue coverage

Variants represented

Richest spec table

44 rows

Recorded power

23 hp

Recorded weight

899 kg

Transmissions

12-speed

Production years

2001-2002

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Compact Utility tractorReference

Four-wheel driveReference

Two-post folding ROPS.Reference

Variants

GT-23gearReference

GT-23FhydrostaticReference

GT-23Jlarge tireReference

Engine

Kubota 1.5L 3-cyl dieselReference

Fuel tank28.0 LReference

Engine16.9 kWReference

Kubota D1463Reference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.5 LReference

Power16.9 kWReference

Rated RPM2500Reference

StarterelectricReference

Starter volts12Reference

Transmission

12-speedReference

hydrostaticReference

Gear Weight899 kgReference

Gears12 forward and 4 reverseReference

Three gears (1-3), plus reverse, in four ranges (creeper and 1-3).Reference

TypehydrostaticReference

Gearsinfinite forward and reverse (3-range)Reference

PTO & Hydraulics

Rear Type1Reference

Rear PTO Type540/750/1000 (1.375)Reference

Dimensions

Wheelbase145 cmReference

Weight1984 to 2072 poundsReference

Front tire6-14Reference

Rear tire9.5-22Reference

Standard tires (ag)Front: 6-14. Rear: 9.5-22Reference

GT-23J Optional tires (ag)Front: 6-14. Rear: 9.5-24Reference

Length285 cmReference

Width118 cmReference

Height (ROPS)189 cmReference

Height (cab)192 cmReference

Hydro Weight939 kgReference

Ground clearance32 cmReference

Front tread94 cmReference

Rear tread94 to 106 cmReference

Electrical

GroundnegativeReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
